Поз.
Артикул
Описание
10
SCREW CONNECTION DELIVERY LINE TO STEERING
15
LINE COOLING LINE
20
HOLLOW SCREW FUEL FEED,AT WATER SEPARATOR
25
SEAL RINGTO 000 296 01 07
30
HOSE DELIVERY LINE
35
HOSE DELIVERY LINE
38
NUT. UNION NUT LINE CONNECTION
40
CUTTING RING. GLAND LINE CONNECTION
45
BUFFER. RUBBER RING PROTECTION AGAINST SCORING FOR HOSE
50
LINE COOLING LINE, X 16755220060929
55
GROMMET RIGHT FRONT SIDE MEMBER, A 438645 F 419551
60
HOSE FROM STEERING GEAR ON COOLING LINE
70
HOSE FROM COOLING LINE TO POWER STEERING PUMP, X 16755120060929
80
GROMMET BRAKE CABLE PASSAGE IN CONSOLE
90
CLAMP22.2 MM
100
HOSE CLAMP LINE MOUNTING
110
CLAMP
120
HOSE CLAMP LINE MOUNTING
130
SCREW PUMP TO BRACKET M 6X20
140
WASHER COMPRESSED AIR LINE TO BRACKET
140
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
150
WASHER COMPRESSED AIR LINE TO BRACKET
160
NUT SPRING-LOADED PUSH ROD
170
HEXAGON HEAD BOLT STEERING TO FRAME M12X160, 20131220
170
HEXAGON HEAD BOLT STEERING TO FRAME M12X1.5X240
170
HEXAGON HEAD BOLT. SCREW PULL ROD TO TRANSFER CASE AND TO SIDE MEMBER
180
WASHER
190
HEXAGON NUT CONSOLE TO REAR CROSS MEMBER
