Поз.
Артикул
Описание
232
ROD FROM ANGULAR LEVER TO INJECTION PUMP
233
ROD FROM CONTROL LEVER TO ANGULAR LEVER
234
NUT TACHOGRAPH TO BRACKET
235
CONICAL CUPTO 102 070 09 75
235
BALL SOCKET , Replaced By: A0009918922
235
BALL SOCKETTO 102 070 09 75, Replaced By: A0009930461
239
BEARING BRACKET ANGULAR LEVER
241
BEARING BRACKET , 952 006483 EXCEPT FOR 005596,005606,005607,005948,005967,005976,005977,006013,006014,006054,006156-006158,006201-006204, 006230-006233,006239,006262,006263,006278,006311-006314,006319-006341,006354-006363,006428-006441.
244
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
244
SCREW , Replaced By: N304017006018
244
SCREW , Replaced By: N304017008016
244
SCREW COVER PLATE TO COVER PLATE M 6 X 12
263
LEVER CONTROL PRESSURE
266
LEVER ANGULAR LEVER
268
LOCK PLATE RELEASE LEVER TO SHAFT
280
LEVER ANGULAR LEVER
287
GUIDE SIGN
294
SPRING
301
BEARING BRACKET REVERSING LEVER
308
SCREW
315
NUT
315
NUT , Replaced By: N304035008001
322
LEVER REVERSING LEVER
329
LOCK PLATE RELEASE LEVER TO SHAFT
336
ROD IDLING CABLE
343
ROD FROM REVERSING LEVER TO ANGULAR LEVER
350
ROD
357
ROD CONTROL PRESSURE
364
BUSHING CONTROL PRESSURE
371
NUT TACHOGRAPH TO BRACKET
378
WASHER COMPRESSED AIR LINE TO BRACKET
378
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
385
COTTER PIN PULL ROD TO LEVER
392
CLIP CABLE TO BRACKET,5 318121
999
ROD
999
BALL SOCKET , Replaced By: A0009918922
999
BALL PIVOT LINK
999
ROLLER ROD TO CONTROL LEVER
999
BEARING BRACKET , Replaced By: A6010706424
999
LEVER ANGULAR LEVER
999
BRACKET BOWDEN CABLE
999
DASHPOT SHOCK ABSORBER
999
BEARING BRACKET ANGULAR LEVER
999
LEVER , 952 006484 ALSO INSTALLED ON 005596,005606,005607,005948,005967,005976,005977,006013,006014,006054,006156-006158,006201-006204, 006230-006233,006239,006262,006263,006278,006311-006314,006319-006341,006354-006363,006428-006441.
999
LEVER , Replaced By: A6160704321
999
LEVER BOWDEN CABLE, 952 006484 ALSO INSTALLED ON 005596,005606,005607,005948,005967,005976,005977,006013,006014,006054,006156-006158,006201-006204, 006230-006233,006239,006262,006263,006278,006311-006314,006319-006341,006354-006363,006428-006441.
999
ROD
999
BEARING BRACKET
999
SPRING
999
WASHER , Replaced By: N000433005304
999
SPRING WASHER ALTERNATOR CONNECTION D+
999
SCREW , Replaced By: N304017006018
999
SCREW CLAMP TO BRACKET AND TO PIPE
999
LOCK PLATE
