Поз.
Артикул
Описание
5
SLEEVE PORT-CLOSING FINE ADJUSTMENT
5
FITTING , Replaced By: A6010740632, +001A6010740228
11
SET SCREW , Replaced By: A6010740228, +001A6010740632
11
SET SCREW PORT-CLOSING FINE ADJUSTMENT
17
SCREW , WITH DIESEL ENGINE
17
COMBINATION BOLT , Replaced By: N304017006019, +001N000137006204
23
SUPPORT INJECTION PUMP
29
SCREW PUMP TO BRACKET
29
SCREW , Replaced By: N304017006016
35
SCREW , Replaced By: N304017008021
35
SCREW PIPE CLAMP
41
WASHER BATTERY MOUNTING, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
47
SEAL RING INJECTION PUMP TO CRANKCASE
53
SCREW BRACKET TO 3/2-WAY VALVE
65
NUT INJECTION PUMP TO CRANKCASE
67
CONNECTOR
69
SEAL RING SCREW PLUG
71
LINE CYLINDER NO.3
71
LINE CYLINDER NO.5
71
LINE CYLINDER NO.1
71
LINE CYLINDER NO.2
71
LINE CYLINDER NO.4
77
BRACKET FUEL LINES NO.1-3
83
SHIM FUEL LINE TO BRACKET
83
SHIM FUEL LINE TO BRACKET
95
BRACKET FUEL LINES NO.1-3
95
LINE FASTENER FUEL LINES NO.1-5
95
BRACKET , Replaced By: A6030780141
107
BRACKET CONTROL LINE TO REGULATING ROD
113
BRACKET CONTROL LINE TO REGULATING ROD
113
BRACKET , Replaced By: A6010782641
119
COMBINATION BOLT , Replaced By: N304017006016
119
SCREW PUMP TO BRACKET
125
BRACKET FUEL LINES NO.4
131
BRACKET FUEL LINES NO.4+5
143
COMBINATION BOLT , Replaced By: N304017006016
143
SCREW PUMP TO BRACKET
145
SCREW , Replaced By: N304017006020
145
SCREW LICENSE PLATE TO BRACKET
147
SPRING WASHER LICENSE PLATE TO BRACKET
179
NOZZLE HOLDER COMBINATION BOSCH,970518 372
179
NOZZLE HOLDER , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0030172921
185
NOZZLE HOLDER (HOLDER BODY) TO 002 017 40 21,002 017 34 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SHIM, 1.0 MM THICK. SPACER WASHER1.0 MM
191
SHIM, 1.45 MM THICK. SPACER WASHER1.45 MM
191
SPACER WASHER1.08 MM
191
SPACER WASHER1.18 MM
191
SPACER WASHER1.68 MM
191
SPACER WASHER0.94 MM
191
SPACER WASHER1.38 MM
191
SPACER WASHER0.80 MM
191
SHIM1.34 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SHIM, 1.95 MM THICK. SPACER WASHER1.95 MM
191
SPACER WASHER1.88 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SPACER WASHER1.70 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SPACER WASHER1.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SPACER WASHER0.88 MM
191
SPACER WASHER1.58 MM
191
SHIM, 1.90 MM THICK. SPACER WASHER1.9 MM
191
SPACER WASHER0.84 MM
191
SHIM, 1.10 MM THICK. SPACER WASHER1.1 MM
191
SHIM, 1.55 MM THICK. SPACER WASHER1.55 MM
191
SPACER WASHER1.48 MM
191
SPACER WASHER1.78 MM, Replaced By: A0040172252
191
SPACER WASHER1.88 MM, Replaced By: A0040173252
191
SPACER WASHER , Replaced By: A0040171252
191
SPACER WASHER , Replaced By: A0030179252
191
SHIM, 1.80 MM THICK. SPACER WASHER1.80 MM, Replaced By: A0040172452
191
SHIM, 1.70 MM THICK. SPACER WASHER , Replaced By: A0040171452
191
SHIM, 1.50 MM THICK. SPACER WASHER1.50 MM, Replaced By: A0030179452
191
SHIM, 1.40 MM THICK. SPACER WASHER , Replaced By: A0030178452
191
SHIM, 1.35 MM THICK. SPACER WASHER1.34 MM, Replaced By: A0030177852
191
SHIM, 1.30 MM THICK. SPACER WASHER1.3 MM
191
SHIM, 1.20 MM THICK. SPACER WASHER1.2 MM
191
SPACER WASHER1.20 MM
191
SPACER WASHER1.30 MM
191
SHIM, 1.05 MM THICK. SPACER WASHER1.04 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SHIM, 1.60 MM THICK. SPACER WASHER1.6 MM
191
SPACER WASHER1.40 MM
191
SPACER WASHER1.50 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SPACER WASHER0.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
191
SHIM, 1.65 MM THICK. SPACER WASHER1.65 MM
191
SHIM, 1.75 MM THICK. SPACER WASHER1.75 MM
191
SPACER WASHER1.28 MM
191
SHIM, 1.25 MM THICK. SPACER WASHER1.24 MM
191
SHIM, 1.85 MM THICK. SPACER WASHER , Replaced By: A0040172852
191
SHIM, 1.15 MM THICK. SPACER WASHER1.15 MM
191
SPACER WASHER1.80 MM
191
SPACER WASHER0.90 MM
197
PRESSURE SPRINGTO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
203
PIN (PRESSURE SPINDLE) TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
209
SPACER WASHERTO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
215
UNION NUT (NOZZLE RETAINING NUT) TO 002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
221
NOZZLE (NOZZLE NEEDLE), TO NOZZLE HOLDER OF MAKE: BOSCH
227
SEAL RING
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
999
SPRING WASHER , Replaced By: N000137008212
