Поз.
Артикул
Описание
8
THRUST BLOCK
12
SELF-ALGN. ROLLER BEARING
16
SEAL RING STEERING WORM SECTOR SHAFT SEALING
16
SEAL RING , Replaced By: A0119978046
20
FLANGE
25
SCREW PIPE CLAMP
25
SCREW , Replaced By: N304017008021
29
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
33
SCREW PLUGROCKINGER,TYP 59 U150
33
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
37
SEAL RING LINE CONNECTION
37
SEAL RING , Replaced By: N007603012111
41
SHAFT
44
COUPLING FLANGE
49
SPACER WASHER
53
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
59
SCREW
63
LOCK PLATE PROPELLER SHAFT TO VIBRATION DAMPER WITH HUB
67
NUT
111
GUIDE TUBE
116
OIL DIPSTICK
119
SEAL RING
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
SCREW PLUG AT BRAKE BOOSTER
999
SEAL RING , Replaced By: N007603012111
999
NUT
999
NUT
999
SCREW REAR EXHAUST PIPE TO MUFFLER
999
SELF-ALGN. ROLLER BEARING
999
SELF-ALGN. ROLLER BEARING
999
LOCK PLATE
999
LOCK PLATE
999
COTTER PINROCKINGER TYP 260 G140
999
THRUST WASHER
999
THRUST BLOCK
999
SPACER WASHER
999
FLANGE
999
THRUST BLOCK
999
THRUST WASHER
999
FLANGE
999
THRUST BLOCK
999
SCREW VIBRATION ABSORBER TO CRANKSHAFT
999
SHAFT
999
SPACER RING
999
FLANGE
999
FLANGE
999
THRUST BLOCK
999
OIL DIPSTICK
999
GUIDE TUBE
999
FLANGE
999
SHAFT
999
SPACER WASHER
999
SPACER RING
999
FLANGE
999
THRUST BLOCK
999
SCREW
999
SEAL RING OUTSIDE
999
SEAL RING
999
SEAL RING , Replaced By: A0009975646
999
SEAL RING
999
SEAL RING , Replaced By: A0059975546
999
SEAL RING , Replaced By: A0179973047
