Поз.
Артикул
Описание
1
STARTING MOTOR12 V, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
2
EXCITER COILTO 002 151 64 01,002 151 69 01, 940 10/50,20/60 211713 940 12/52,22/62 008163
2
EXCITER COIL , Replaced By: A0001516555
2
EXCITER COIL , Replaced By: A0001514755
3
SCREWTO 343 151 71 01
4
CARBON BRUSH SETTO 002 151 64 01,002 151 69 01
8
PINION , Replaced By: A0001519613
8
PINION *** TO 002 151 64 01.002 151 69 01
9
BUSHING DRIVE END BEARING TO 003 151 07 01,001 151 64 01
10
BUSHINGTO 004 151 58 01/003 151 87 01
15
SOLENOID SWITCHTO 002 151 30 01/69 01/003 151 07 01
16
REPAIR KIT ARMATURE MOUNTING
19
SCREW BRACKET TO FRAME
21
SPRING WASHER AIR COMPRESSOR LINE TO ENGINE,5 812731 - 5 8174215 936366 - 5 999999K 000001N 817422K 126820
21
SPRING WASHER CAB FLOOR
24
NUT STRAP TO SUPPORT,5 149419
25
ANGLE
26
SCREW , Replaced By: N304017006016
26
SCREW PUMP TO BRACKET
27
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
27
WASHER COMPRESSED AIR LINE TO BRACKET
999
CONTROL LEVERTO 001 151 96 01
999
SPRINGTO 002 151 64 01/002 151 65 01
999
BUSHINGTO 004 151 58 01
999
BUSHING INTERMEDIATE BEARING TO 002 151 64 01,002 151 69 01, 940 10/50,20/60 211713 940 12/52,22/62 008163
999
RECTIFIER , Replaced By: A0001543216
999
PULLEY
999
FAN , Replaced By: A0001556618
999
PULLEY , Replaced By: A0001557115
999
FAN
999
PULLEY
999
PULLEY
999
ALTERNATOR , Replaced By: A0031546702
999
NUT , Replaced By: N913017005000
999
GROUND CABLE , Replaced By: A6151500232
999
SCREW , Replaced By: A0069909101
999
NUT
