Поз.
Артикул
Описание
7
COVERING ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM,4 921287
7
ANTINOISE CAPSULE ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM,4 921200
7
COVERING ENGINE,BOTTOM
7
COVERING ENGINE,BOTTOM
7
COVERING ,4 921199 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6175201222, +002A6175241440, +002A6175241540
7
COVERING ,4 921199 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6175201322, +002A6175241440, +002A6175241540
35
BRACKET COVER PLATE,4 921199
55
BRACKET COVER PLATE,4 921199
59
BRACKET COVER PLATE,4 8119264 921287
59
BRACKET ,4 811925, Replaced By: A3835242340, +001N000961012093
63
BRACKET LEFT COVERING,4 921199
63
BRACKET RIGHT COVERING,4 921199
67
BRACKET RIGHT COVERING
67
BRACKET LEFT COVERING
79
SCREW , Replaced By: N304017008034
83
NUT , Replaced By: N913004008001
83
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
87
SCREW PIPE CLAMP
87
SCREW END PIECE TO EXHAUST PIPE M 10X25
87
SCREW , Replaced By: N304017008021
88
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
91
WASHER RADIATOR TO RUBBER MOUNTING
91
WASHER , Replaced By: N000125010532
95
NUT , Replaced By: N910113010000
95
NUT STRAP TO BRACKET
100
WASHER BRACKET TO LEFT SIDE MEMBER
100
WASHER , Replaced By: N009021008213
101
SCREW BRACKET TO LEFT SIDE MEMBER
101
SCREW BRACKET TO FRAME M 12X35
999
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
