Поз.
Артикул
Описание
9
FUEL TANK , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 169122, Replaced By: A6524700101, +001A0005409917, +001A0115426017
9
FUEL TANK ,K 169123, Replaced By: A6704700101
9
FUEL TANK125 L,K 169123
17
COVERING FUEL GAUGE
25
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
33
FILLER CAP
33
FILLER CAP , Replaced By: A0004700305
33
FILLER CAP , Replaced By: A0004700305
33
FILLER CAP , Replaced By: A0004700305
41
SEAL RING
49
CHAIN FILLER CAP
57
SENDER UNIT , Replaced By: A0085428917
65
SUPPORT FUEL TANK
73
SHIM CONSOLES TO SIDE MEMBER
73
SHIM CONSOLE TO SIDE MEMBER
81
SCREW , Replaced By: N308676014020
81
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
89
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
97
STRAP FUEL TANK TO SUPPORT
105
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
113
PAD FUEL TANK TO SUPPORT, ORDER BY THE METER
121
STOP
129
WASHER
137
NUT SUPPORT TO SIDE MEMBER
145
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
145
PLASTIC PIPE RISING PIPE 4X6 MM
153
HOSE LEAK LINE, ORDER BY THE METER
161
SLEEVE LEAK LINE
165
HOSE FEED TO,AND RETURN FROM,OIL FILTER
169
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
177
LOOM TIE LINE MOUNTING 280 MM
185
CLAMP LINE MOUNTING
193
LINE FUEL COMPENSATING
201
HOSE LEAK LINE
209
CLAMP , Replaced By: N916017011001
209
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
217
HOLLOW SCREW , Replaced By: N915036010108
217
HOLLOW SCREW FUEL LINE TO FEED PUMP
225
SEAL RING FUEL LINE TO FEED PUMP
233
BRACKET FUEL LINE
241
SCREW HOOK TO BRACKET
241
SCREW , Replaced By: N007985005175
249
WASHER , Replaced By: N000433005304
249
WASHER BOOT TO CAB FLOOR
257
NUT TWO-WAY VALVE TO BRACKET
265
CLAMP FUEL LINE TO BRACKET
265
CLAMP , Replaced By: A3129952420
265
CLAMP , Replaced By: A1109950401
273
RUBBER PAD FUEL LINE TO BRACKET
281
SCREW HOOK TO BRACKET
281
SCREW , Replaced By: N007985005175
289
NUT TWO-WAY VALVE TO BRACKET
