Поз.
Артикул
Описание
11
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
19
FITTING , Replaced By: A0029905971
19
FITTING (PARTS KIT),LINE RUPTURE
27
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
31
BANJO UNION HEATING CONNECTION,K 169122
35
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
43
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION 6 MM
48
BRACKET LINE MOUNTING
51
LOOM TIE LINE MOUNTING 280 MM
65
VALVE (HAND BRAKE VALVE) WABCO, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
65
VALVE (HAND BRAKE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
65
VALVE (HAND BRAKE VALVE) KNORR, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
65
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0034300081
73
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0034300181
73
VALVE (HAND BRAKE VALVE) BOSCH
73
VALVE (HAND BRAKE VALVE) KNORR, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
73
VALVE (HAND BRAKE VALVE) WABCO, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
76
PROTECTIVE CAPTO WABCO
79
PROTECTIVE CAPTO BOSCH
79
PROTECTIVE CAPKNORR
81
HANDLETO BOSCH
81
HANDLEKNORR
81
HANDLETO WABCO
89
REPAIR KITTO BOSCH
89
REPAIR KITTO 001 430 58 81/59 81,WABCO, WITH HAND BRAKE VALVE ON ENGINE TUNNEL, FROM IDENT NO. SEE MF 26032
89
REPAIR KIT , Replaced By: A0034303381
89
REPAIR KIT HAND BRAKE LEVER TO WABCO
89
REPAIR KITTO 003 430 00 81/01 81,KNORR
89
REPAIR KITTO 001 430 35 81/44 81,BOSCH
113
HOLLOW SCREW HEATING CONNECTION
119
HOLLOW SCREW , Replaced By: N915036010108
119
HOLLOW SCREW FUEL LINE TO FEED PUMP
121
SEAL RING LINE CONNECTION
123
SEAL RING FUEL LINE TO FEED PUMP
125
VALVE (LOCKING VALVE) WABCO
125
VALVE (LOCKING VALVE) VOSS
127
SEAL RINGTO 003 429 46 44,WABCO
128
ELBOW FITTING RELAY VALVE,CONNECTION: "20"
128
FITTING SHUTTLE VALVE,CONNECTION: "20",5 727399
128
FITTING RELAY VALVE,CONNECTION: "40"
130
NUT CHECK VALVE TO AIR RESERVOIR
130
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
131
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
131
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
131
THRUST RING CHECK VALVE TO AIR RESERVOIR
132
O-RING CHECK VALVE TO AIR RESERVOIR
132
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
132
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
133
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
134
SEAL RING FUEL LINE TO FEED PUMP
135
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
135
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
136
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
136
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
137
VALVE (LOCKING VALVE) VOSS
137
VALVE (LOCKING VALVE) WABCO
140
SEAL RINGTO 003 429 46 44,WABCO
169
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
177
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
185
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
185
SEAL RING
201
HOLLOW SCREW FUEL LINE TO FEED PUMP
201
HOLLOW SCREW FUEL LINE TO FEED PUMP
201
HOLLOW SCREW , Replaced By: N915036010108
217
SEAL RING FUEL LINE TO FEED PUMP
217
SEAL RING FUEL LINE TO FEED PUMP
217
SEAL RING FUEL LINE TO FEED PUMP
219
ELBOW FITTING RELAY VALVE,CONNECTIONS: "21,22"
220
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
221
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
222
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
225
FITTING RELAY VALVE,CONNECTION "20",LEFT
229
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
233
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
241
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
249
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
255
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
999
HOLLOW SCREW LINE CONNECTION
999
T-FITTING AIR RESERVOIR,CONNECTION: "31"
999
VALVE PARKING BRAKE VALVE BOSCH
999
VALVE PARKING BRAKE VALVE BOSCH
999
REPAIR KITTO 001 430 68 81/69 81,KNORR
999
ADAPTER FITTING , Replaced By: A0004296934
