Поз.
Артикул
Описание
142
PUMP (HAND PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
142
PUMP (HAND PUMP) WEBER
144
PISTON , Replaced By: A0005531990
144
PISTONWEBER,TO 000 553 40 01
144
PISTONTO 000 553 79 01,WEBER
146
LEVERTO 000 553 37 01,000 553 39 01,WEBER
148
VALVEWEBER,TO 000 553 40 01
148
VALVETO 000 553 79 01,WEBER
148
VALVETO 000 553 88 01
150
SEAL RINGTO 000 553 23 01,000 553 37 01,
152
CLAMPING SLEEVE4X28 MM,TO 000 553 23 01,,4 250876
154
CLAMPING SLEEVE4X12 MM,TO 000 553 23 01,
156
SCREW , Replaced By: N000000000190
156
SCREW
158
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
160
GASKETWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
162
FILTER
164
SEAL RING , UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
166
SEAL RINGTO 000 553 23 01,000 553 37 01,,4 250876
168
SEAL RINGTO 000 553 23 01,000 553 37 01,
170
SEAL RINGTO 000 553 37 01,000 553 39 01,WEBER,4 250876
172
FITTED WASHER
174
LOCK RING
176
SEAL RING , UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
178
SEAL RING , UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
180
BUSHINGTO 000 553 37 01,000 553 39 01,WEBER
182
SCREW , Replaced By: A0009901310
182
SCREW
182
SCREW OIL FILLING TO 000 553 89 01
184
SEAL RINGTO 000 553 23 01,000 553 37 01,
186
WASHERWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
188
SNAP RINGWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
190
SNAP RINGWEBER,TO 000 553 40 01, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
191
GASKET KIT HAND PUMP
191
GASKET KIT HAND PUMP
192
GUIDEWEBER,TO 001 553 45 05
192
GUIDEWEBER,TO 000 553 75 05, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
192
CYLINDER , Replaced By: A0015534605
192
CYLINDER POWER CYLINDER, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
193
GUIDEWEBER,TO 000 553 75 05, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
193
GUIDEWEBER,TO 001 553 45 05
194
GASKET KIT HYDRAULIC CYLINDER POWER PACKER
194
GASKET KIT , Replaced By: A0005500507
194
GASKET KIT HYDRAULIC CYLINDER WEBER,TO 000 553 75 05, UP TO IDENT NO. 5 070891,FROM IDENT NO. SEE SA 31 460
194
REPAIR KIT , Replaced By: A0005500107
400
BEARING BRACKET , Replaced By: A6205531738
400
BEARING BRACKET , Replaced By: A6205531738
400
BEARING BRACKET , Replaced By: A6205531638
400
BEARING BRACKET HYDRAULIC CYLINDER
400
BEARING BRACKET , Replaced By: A6555530238
402
SCREW BEARING BRACKET TO SIDE MEMBER
402
SCREW , Replaced By: N308676016013
402
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X40
404
NUT , Replaced By: N910113016001
404
NUT CONSOLE TO SUPPORT
406
SCREW HYDRAULIC CYLINDER BEARING BRACKET TO FRAME M 16X25
406
SCREW SHACKLE TO CONSOLE
408
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
NUT , Replaced By: N910113014001
999
NUT , Replaced By: N913004008001
999
NUT BRACKET TO SIDE MEMBER
999
NUT SUPPORT TO SIDE MEMBER
999
RIVET FRAME TRUSS TO SIDE MEMBER
999
SPRING WASHER LEVER MOUNTING
999
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
SCREW BRACKET TO CROSS CONNECTION STRUT
999
SCREW , Replaced By: N308676014020
999
SCREW , Replaced By: N308676012012
999
SCREW , Replaced By: N304017008034
999
COTTER PIN LEVER TO ROD
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
SPACER TUBE HOLLOW RUBBER SPRING,5 956658
999
WASHER , Replaced By: A6558910210
999
SHIM SHOCK ABSORBER
999
BRACKET RIGHT SHOCK ABSORBER
999
PIN , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT
999
MOUNTING SPRING AND STABILIZER,RIGHT
999
MOUNTING SPRING AND STABILIZER,LEFT
999
STABILIZER , Replaced By: A6528900104
999
MOUNTING ,5 178428, Replaced By: A6218900503, +001A6203100177
999
MOUNTING ,5 178428, Replaced By: A6218900403, +001A6203100177
999
CONSOLE CAB SUSPENSION,FRONT RIGHT
999
CONSOLE CAB SUSPENSION,FRONT LEFT
999
BOW VIBRATION ABSORBER TO BEARING AND TO CAB,5 500828
999
STRUT BUMPER,RIGHT
999
STRUT BUMPER,LEFT
999
WASHER VIBRATION ABSORBER TO BEARING AND TO CAB
999
STRUT BUMPER,RIGHT
999
STRUT BUMPER,LEFT
999
REPAIR KIT CAB FRONT SUSPENSION STABILIZER
999
REPAIR KIT CAB FRONT SUSPENSION STABILIZER,5 178428
999
MOUNTING SHOCK ABSORBER, NOT USED
999
CONSOLE CAB SUSPENSION, NOT USED
999
MOUNTING CAB, RIGHT
999
MOUNTING CAB,LEFT
999
MOUNTING , Replaced By: A6558910420
999
MOUNTING , Replaced By: A6558910320
999
MOUNTING CAB, RIGHT
999
MOUNTING LEFT SIDE MEMBER
999
LEVER (TILTING LEVER),CAB
999
LEVER (TILTING LEVER),CAB
999
WASHER STABILIZER TO BEARING
999
SPRING (LEAF SPRING),CAB SUSPENSION
999
BRACKET BUFFER
999
SPRING CAB SUSPENSION,FRONT
999
SHIM MOUNTING TO CONSOLE
999
SPACER TUBE VIBRATION ABSORBER TO CONSOLE
999
SPACER TUBE MOUNTING TO CONSOLE
999
SHACKLE
999
SHACKLE
999
LEVER
999
LEVER , NO LONGER AVAILABLE, ORDER INDIVIDUAL PARTS
999
LEVER , NO LONGER AVAILABLE,ORDER INDIVIDUAL PARTS
999
LEVER CAB SUSPENSION
999
RAIL , Replaced By: A6558900122
999
RAIL , Replaced By: A3878901222
999
REPAIR KIT , Replaced By: A3879920003, +002A6208910017, +001A3638910023
999
GUIDE SIGN DANGER AREA IN FRONT OF TILTED CAB
999
BRACKET RIGHT FENDER
999
BRACKET LEFT FENDER
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
WASHER BEARING BRACKET
999
REPAIR KIT CAB SUSPENSION,FRONT
999
GUMMED LABEL CAB LOCKING MECHANISM
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
BUSHING SPRING
999
BUFFER (HOLLOW RUBBER SPRING),CAB
999
FLANGE HOLLOW RUBBER SPRING
999
WASHER LEFT AND RIGHT CONSOLES TO CAB
999
MOUNTING (RUBBER BUFFER)
999
WASHER BRACKET TO SIDE MEMBER,5 703114
999
PIN PULL TO FASTENER
999
CYLINDER HYDRAULIC SYSTEM USED FOR CAB TILTING POWER PACKER
999
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
999
SHOCK ABSORBER (VIBRATION ABSORBER),CAB REAR SUSPENSION
999
PUMP (HAND PUMP) POWER PACKER,4 733732
999
PUMP , Replaced By: A0005536501
