Поз.
Артикул
Описание
5
PUMP , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A0005719501
5
PUMP WITH FILLER CAP BEKA-MAX
5
PUMP WITH FILLER CAP BEKA-MAX
8
ELECTRIC MOTORBEKA-MAX,TO 000 571 46 01, 54 01
8
ELECTRIC MOTOR , Replaced By: A0005402488
11
SHAFT , Replaced By: A0005710135
11
SHAFT
14
CLAMPING PIN2X12 MM
17
PLUG NOT CONFORMING TO DANGEROUS GOODS TRAFFIC REGULATIONS (GGVS)
20
SUCTION PIPE WITH GEARED PUMP BEKA-MAX,TO 000 571 4601, 5401
20
SUCTION PIPE WITH GEARED PUMP BEKA-MAX,TO 000 571 4601, 5401
20
SUCTION PIPE , Replaced By: A0005700256
23
PUMP WITH GEAR BEKA-MAX
23
PUMP WITH GEAR BEKA-MAX
23
PUMP , Replaced By: A0005719401
26
RESERVOIR PUMP BEKA-MAX
26
RESERVOIR , Replaced By: A0005700204
29
GASKETBEKA-MAX
29
GASKETBEKA-MAX
29
SEAL RING , Replaced By: A0005710780
32
VALVE GREASE FILLING BEKA-MAX
32
VALVE GREASE FILLING BEKA-MAX
32
VALVE , Replaced By: A0005711614
35
COVER GREASE FILLING
38
GASKET , Replaced By: A1020180380
38
GASKET , Replaced By: A1020180380
38
GASKET
41
COVER PUMP BEKA-MAX
41
COVER , Replaced By: A0005711703
44
RETAINING PLATE PUMP BEKA-MAX,TO 000 571 54 01,70 01
44
RETAINING PLATE PUMP VOGEL,TO 000 571 54 01,70 01
44
RETAINING PLATE PUMP VOGEL,TO 000 571 54 01,70 01
47
CONSOLE OIL TANK
47
CONSOLE CENTRAL LUBRICATION PUMP
47
CONSOLE CENTRAL LUBRICATION PUMP
47
CONSOLE PUMP TO REAR CROSS MEMBER SA 26630, 26631, 33003, 33004, FOR SEMITRAILERS
47
SUPPORT , TO BE ADAPTED DURING ASSEMBLY, Replaced By: A6205200733
47
SUPPORT , Replaced By: A6205280939
50
BRACKET SUPPORT TO FRAME
53
SCREW BRACKET TO EXHAUST MUFFLER BRACKET
56
NUT SUPPORT TO SIDE MEMBER
59
SHIM COMPRESSED AIR LINE TO ENGINE
59
SHIM , Replaced By: A6455280184
62
SCREW , Replaced By: N308676016006
62
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
65
NUT CONSOLE TO SUPPORT
65
NUT , Replaced By: N910113016001
68
CONSOLE CENTRAL LUBRICATION PUMP
68
CONSOLE CENTRAL LUBRICATION PUMP
68
CONSOLE CENTRAL LUBRICATION PUMP
71
SCREW EXHAUST PIPE TO BRACKET
71
SCREW EXHAUST PIPE TO BRACKET
71
SCREW , Replaced By: A4609900601
74
NUT , Replaced By: N913004008001
74
NUT , Replaced By: N913004008001
999
CONSOLE PUMP TO FRAME SIDE MEMBER SA 26687/22/25/26,33003/10/12,33004/14, NOT FOR CHASSIS MODEL 652
999
BRACKET PUMP TO REAR CROSS MEMBER SA 33.529/01, FOR SEMITRAILERS
