Поз.
Артикул
Описание
11
COVER
11
COVERING
11
COVERING , Replaced By: A0008661930
104
COVERING FECES CONTAINER
107
BUFFER WASHROOM DOOR
108
MOUNTING
110
SWITCH WASHROOM DOOR
113
SWITCH DOOR LOCK
116
STOP DOOR STOP
119
CAP PLASTIC
122
MORTISE LOCK. FASTENER WASHROOM DOOR
125
DOOR HANDLE VACANT-OCCUPIED SET
125
DOOR HANDLE WASHROOM DOOR
128
RUBBER SECTION WASHROOM DOOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
129
RUBBER SECTION WASHROOM DOOR, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
131
SEAL
248
GASKET , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
251
SCREW BRACKET TO SIDE MEMBER M8X20
254
NUT-AND-WASHER ASSEMBLY RUBBER MOUNTING TO FRAME M8
257
COVERING
260
TAPPING SCREW BRACKET TO CAB FLOOR 3.5X9.5
263
COVERING
263
COVERING
264
ANGLE
265
SPACERTO 613 640 11 09/12 09
266
SHEET METAL SCREW. SCREWST25X 6 T20
269
LOCKING CAP
272
FIXTURE
275
DRAIN WATER DRAIN
278
PLYWOOD , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
278
FLOOR , Replaced By: A0009837380
278
BOTTOM , Replaced By: A0009837380
278
BOTTOM , Replaced By: A0009837380
279
GROMMET15 X 18,5 MM
279
GROMMET
287
ADHESIVE STRIP. BASE40 X 2 MM
290
SHEET METAL SCREW. SCREW
299
CAP GRIP RAIL
311
COVERING
332
W.C. DOOR. W.C. DOORRHD, DETERMINE COVER FABRIC VIA VEDOC "NFC 5117"
335
COVERINGH - PROFIL, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
437
COVERING
446
FITTING
455
GROMMET
473
LOCK PNEUMATICALLY CONTROLLED
473
FASTENER MECHANICAL
473
LOCK LAVATORY DOOR MECHANICAL
479
INSULATING TAPE
485
COVERING1044X46,5X12
488
COVERING
512
EDGE TRIMALU, ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
515
PLASTIC SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
518
LEDGE
521
TAPPING SCREW3.5X19
521
TAPPING SCREW AT BRACKET 2.9X9.5
524
SMOKE DETECTORORS 142
527
SMOKE DETECTOR SOCKET TO BODY
536
SEAL
539
SCREEN
542
FITTING
545
HOSE , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
548
CLAMP44 - 60/9
560
SQUARE KEY WASHROOM DOOR
999
COVERING
999
SEAL
999
COVER
999
SHAPED SECTIONPVCH - PROFIL GEBOGEN
999
SPIRAL SPRING
999
SEALING COMPOUND
999
COMPRESSED AIR LINE
999
PLUG SOCKET
999
SOCKET-OUTLET220 V
999
FASTENER
999
LAVATORY TOILET CABIN
999
LAVATORY TOILET CABIN
999
COVERING CORNER COVER
999
COVERING CORNER COVER
999
SECTION , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
