Поз.
Артикул
Описание
865
NUT COMBINATION CYLINDER TO BEARING BRACKET
865
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
868
BEARING BRACKET WHEEL CYLINDER, IN CASE OF CAST AXLE
871
SCREW BEARING BRACKET TO REAR AXLE
874
SCREW BEARING BRACKET TO REAR AXLE M16X1.5X70
874
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
874
SCREW , Replaced By: N308676016006
877
CLAMPING SLEEVE BEARING BRACKET TO REAR AXLE
880
BRAKE ANCHOR TRISTOP CYLINDER
883
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
886
NUT BRACKET TO SIDE MEMBER
886
NUT , Replaced By: N910113014001
889
PIN COMBINATION CYLINDER TO SLACK ADJUSTER
892
WASHER COMBINATION CYLINDER TO SLACK ADJUSTER
892
WASHER , Replaced By: N000433015005
895
COTTER PIN STRAP TO SUPPORT
910
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
910
VALVE PARKING BRAKE VALVE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
910
VALVE PARKING BRAKE VALVE KNORR
910
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0024309981
910
VALVE PARKING BRAKE VALVE KNORR
910
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0024309881
910
VALVE PARKING BRAKE VALVE BOSCH
910
VALVE PARKING BRAKE VALVE BOSCH
913
HANDLETO WABCO
913
HANDLEKNORR
913
HANDLETO BOSCH
921
PROTECTIVE CAPTO WABCO
921
PROTECTIVE CAPKNORR
921
PROTECTIVE CAPTO BOSCH
924
CLAMPING SLEEVEKNORR
927
REPAIR KITTO BOSCH
930
REPAIR KITTO 001 430 56 81,001 430 57 81
930
REPAIR KIT , Replaced By: A0034303181
933
SCREW PARKING BRAKE VALVE TO WINDOW SILL
936
LOCK WASHER PARKING BRAKE VALVE TO WINDOW SILL
939
GUMMED LABEL PARKING BRAKE ACTUATION
942
COUPLING FROM CHECK VALVE TO PARKING BRAKE VALVE
946
SEAL RING
999
FITTINGWABCO
999
DIAPHRAGM , Replaced By: A0004290745
999
DIAPHRAGM
999
ELBOW FITTING , Replaced By: A0004294638
999
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
999
ADAPTER FITTING LINE CONNECTION TO ENGINE
999
REPAIR KIT PRESSURE REGULATOR KNORR
999
REPAIR KIT , Replaced By: A0024209824, +002A0024209424
999
ANGLETO 000 431 46 15
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
CONNECTOR REPAIR SIZE
999
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
999
ELBOW FITTING ,5 433281
999
T-FITTING CHECK VALVE TO RELAY VALVE
999
ELBOW FITTING , Replaced By: A0019908171
999
REPAIR KITTO 002 430 98 81,99 81,KNORR
999
REPAIR KITTO 001 430 66 81,001 430 67 81,KNORR
999
ADHESIVE FOIL GUIDE SIGN
999
BRACKET AIR DEHYDRATOR
999
REPAIR KIT. TS SEALING RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 22
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
NUT COMPRESSED AIR LINE THRU FRAME,5 395034
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
999
WASHER STRAP TO SUPPORT
999
SEAL RING LINE CONNECTION
999
NUT STRAP TO BRACKET
999
NUT , Replaced By: N910113010000
