Поз.
Артикул
Описание
5
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 906164, Replaced By: A6505010601
5
RADIATOR WATER
5
RADIATOR , Replaced By: A6505011201
8
SCREW WATER DRAIN
11
LOCK
17
SUPPORT RADIATOR,LEFT,K 096750
17
SUPPORT RADIATOR,RIGHT,K 096749
17
SUPPORT RADIATOR,RIGHT,K 096750
17
SUPPORT RADIATOR,LEFT,K 096749
20
SCREW , Replaced By: N000961012025
20
SCREW SUPPORT TO SIDE MEMBER
23
NUT SUPPORT TO SIDE MEMBER
26
RUBBER MOUNTING RADIATOR
32
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
32
SCREW , Replaced By: N304017010028
35
WASHER , Replaced By: N000125010532
35
WASHER RADIATOR TO RUBBER MOUNTING
44
FAN SHROUD RADIATOR
53
CLIP-TYPE NUT FAN SHROUD TO RADIATOR
59
TANK COOLING WATER EXPANSION
62
RADIATOR CAP FILLER NECK
62
RADIATOR CAP , Replaced By: A0005016415
65
SEAL RING
68
RADIATOR CAP
71
RADIATOR CAP CENTRAL
71
RADIATOR CAP CENTRAL
74
GASKET O.D., 52 MM
77
GASKET O.D., 37 MM
80
DRAIN PIPE
83
SENDER UNIT COOLING WATER LEVEL INDICATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR 48X40 MM
86
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
89
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
92
HOSE FROM EXPANSION TANK TO RADIATOR
95
CLAMP , Replaced By: N916017011001
95
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
98
BRACKET OI DIPSTICK GUIDE TUBE
104
CLAMP OIL DIPSTICK TO RADIATOR
107
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
107
SCREW , Replaced By: N304017008016
