Поз.
Артикул
Описание
8
RADIATOR WITH SCREW FITTING
8
RADIATOR , FROM IDENT NO. 5 623090, SEE STANDARD MICROFICHE, Replaced By: A6525016601, +001A6552602262, +001A6552602985, +001A6552603085, +001A6559974182, +001A6559974682
8
RADIATOR ,K 115007
8
RADIATOR WITH SCREW FITTING,K 115008
8
RADIATOR , Replaced By: A6525016901
8
RADIATOR , Replaced By: A6525014901
8
RADIATOR
8
RADIATOR , Replaced By: A6525014201
8
RADIATOR , Replaced By: A6525014201
8
RADIATOR , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 5 752618, Replaced By: A6525012501
9
SCREW , Replaced By: A0005000085
9
SCREW WATER DRAIN
10
GASKET COOLING WATER DRAIN TO 656 500 00 03
11
LOCK
29
RUBBER MOUNTING RADIATOR
38
SCREW , Replaced By: N304017010028
38
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
41
WASHER RADIATOR TO RUBBER MOUNTING
41
WASHER , Replaced By: N000125010532
44
FAN SHROUD RADIATOR
44
FAN SHROUD
47
DETENT FAN SHROUD TO RADIATOR
50
LOCK , Replaced By: N912002008003
50
LOCK PULL TO FASTENER
56
BOOT FAN SHROUD TO FAN RING
56
BOOT , Replaced By: A6565050286
56
BOOT FAN SHROUD TO FAN RING
57
BOOT (SEALING LIP)
58
BRACKET SEALING LIP TO RADIATOR
59
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
59
BRACKET SEALING LIP TO OIL DIPSTICK BRACKET
60
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
61
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
61
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
62
BRACKET SEALING LIP TO EXPANSION TANK
63
PIN SEALING LIP TO EXPANSION TANK
64
TANK COOLING WATER EXPANSION
65
RADIATOR CAP , Replaced By: A0005016415
65
RADIATOR CAP FILLER NECK
66
SEAL RING
68
RADIATOR CAP
71
RADIATOR CAP CENTRAL
71
RADIATOR CAP CENTRAL
74
GASKET O.D., 52 MM
77
GASKET O.D., 37 MM
80
DRAIN PIPE
83
SENDER UNIT COOLING WATER LEVEL INDICATOR
86
PLATE FROM EXPANSION TANK TO RADIATOR 40X40 MM
86
PLATE FROM EXPANSION TANK TO RADIATOR
89
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
92
HOSE FROM EXPANSION TANK TO ENGINE
92
HOSE , Replaced By: A6565010382
95
CLAMP , Replaced By: N916017011001
95
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
143
BRACKET OIL DIPSTICK GUIDE TUBE
146
SCREW GUIDE TUBE BRACKET TO RADIATOR
146
SCREW , Replaced By: A2019900936
149
BRACKET ,5 4800455 480046K 037736, Replaced By: A6525281040, +001A4412050840
149
BRACKET OIL DIPSTICK GUIDE TUBE
149
BRACKET OIL DIPSTICK GUIDE TUBE TO BRACKET
152
SCREW PUMP TO BRACKET
152
SCREW COVER PLATE TO BRACKET
152
SCREW , Replaced By: N304017006016
155
NUT , Replaced By: N913004006001
155
NUT PUMP TO BRACKET
158
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
161
SCREW , Replaced By: N304017008016
164
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
164
NUT , Replaced By: N913004008001
164
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
CLAMP , Replaced By: A3609951201
999
CLAMP AT BRACKET
