Поз.
Артикул
Описание
33
COVERING CHASSIS
34
COVERING CHASSIS
34
COVERING CHASSIS
34
COVERING , Replaced By: A6455241433
34
COVERING CHASSIS
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
44
SHEET METAL SCREW COVER PLATE TO CAB REAR PANEL
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COVERING TO CAB
52
WASHER COMPRESSED AIR LINE TO BRACKET
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
52
WASHER COMPRESSED AIR LINE TO BRACKET
58
BOOT CROSS CONNECTION
72
BRACKET CROSS CONNECTION
72
BRACKET CROSS CONNECTION
72
BRACKET ,5 002371 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 5 592740, Replaced By: A6204290068
72
BRACKET ,5 002371 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 5 592740, Replaced By: A6204290068
72
BRACKET ,5 002371 EXHAUST STOCK OF OLD PART NUMBERS FIRST UP TO IDENT NO. 5 592740, Replaced By: A6204290068
77
SCREW END PIECE TO EXHAUST PIPE M 10X25
77
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
78
WASHER , Replaced By: N000125010532
78
WASHER RADIATOR TO RUBBER MOUNTING
78
WASHER , Replaced By: N009021010209
78
WASHER BRACKET TO COVERING
79
NUT , Replaced By: N910113010000
79
NUT STRAP TO BRACKET
79
NUT STRAP TO BRACKET
188
MOUNTING ANGLE BRACKET TO MOUNTING ANGLE
188
MOUNTING ANGLE COVERING
188
MOUNTING ANGLE BRACKET TO MOUNTING ANGLE
196
SCREW , Replaced By: N304017008021
196
SCREW PIPE CLAMP
196
SCREW PIPE CLAMP
196
SCREW PIPE CLAMP
196
SCREW PIPE CLAMP
204
WASHER , Replaced By: N000125008443
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER , Replaced By: N009021008213
204
WASHER BRACKET TO LEFT SIDE MEMBER
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER EXHAUST MUFFLER TO STRAP
204
WASHER BRACKET TO LEFT SIDE MEMBER
208
NUT , Replaced By: N913004008001
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
208
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
229
BRACKET RIGHT
229
BRACKET RIGHT
232
SCREW CONSOLE TO SIDE MEMBER
232
SCREW , Replaced By: N308676012026
232
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
232
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
232
SCREW END PIECE TO EXHAUST PIPE M 10X25
233
WASHER
233
WASHER , Replaced By: N000125010532
233
WASHER RADIATOR TO RUBBER MOUNTING
234
NUT SUPPORT TO SIDE MEMBER
234
NUT , Replaced By: N910113010000
234
NUT STRAP TO BRACKET
236
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
239
WASHER , Replaced By: N000125010532
239
WASHER RADIATOR TO RUBBER MOUNTING
241
NUT , Replaced By: N910113010000
241
NUT STRAP TO BRACKET
244
BRACKET , Replaced By: A6205240340
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET COVERING
244
BRACKET LEFT
244
BRACKET COVERING, TO BE ADAPTED DURING ASSEMBLY
244
BRACKET , Replaced By: A6735460243
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET FUEL LINES TO TRANSMISSION
244
BRACKET COVERING,5 736351
244
BRACKET , Replaced By: A6555240040
244
BRACKET , Replaced By: A6555240040
244
BRACKET COVERING
244
BRACKET FUEL LINES TO TRANSMISSION
245
BRACKET COVERING
306
BRACKET COVERING
307
BRACKET COVERING
307
BRACKET COVERING
308
SCREW REAR EXHAUST PIPE TO MUFFLER
308
SCREW EXHAUST PIPE TO BRACKET
308
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
308
SCREW REAR EXHAUST PIPE TO MUFFLER
308
SCREW REAR EXHAUST PIPE TO MUFFLER
308
SCREW , Replaced By: N304017010002
308
SCREW BRACKET TO SIDE MEMBER
312
WASHER , Replaced By: N000125010532
312
WASHER RADIATOR TO RUBBER MOUNTING
312
WASHER RADIATOR TO RUBBER MOUNTING
312
WASHER RADIATOR TO RUBBER MOUNTING
316
NUT , Replaced By: N910113010000
316
NUT STRAP TO BRACKET
316
NUT STRAP TO BRACKET
316
NUT STRAP TO BRACKET
332
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
332
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
332
SCREW END PIECE TO EXHAUST PIPE M 10X25
332
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
332
SCREW END PIECE TO EXHAUST PIPE M 10X25
332
SCREW END PIECE TO EXHAUST PIPE M 10X25
332
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
340
WASHER , Replaced By: N000125010532
340
WASHER RADIATOR TO RUBBER MOUNTING
340
WASHER RADIATOR TO RUBBER MOUNTING
340
WASHER RADIATOR TO RUBBER MOUNTING
343
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
344
NUT , Replaced By: N910113010000
344
NUT STRAP TO BRACKET
344
NUT STRAP TO BRACKET
344
NUT STRAP TO BRACKET
344
NUT STRAP TO BRACKET
344
NUT STRAP TO BRACKET
346
SCREW , Replaced By: N304017008027
346
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
346
SCREW , Replaced By: N304017008016
346
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
347
WASHER , Replaced By: N000125008443
347
WASHER EXHAUST MUFFLER TO STRAP
347
WASHER EXHAUST MUFFLER TO STRAP
349
NUT , Replaced By: N913004008001
349
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
349
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
350
BRACKET COVERING
351
BRACKET COVERING
353
BRACKET COVERING
353
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
353
BRACKET COVERING
353
BRACKET , Replaced By: A6205240340
353
BRACKET FUEL LINES TO TRANSMISSION
355
SCREW END PIECE TO EXHAUST PIPE M 10X25
357
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
357
SCREW , Replaced By: N304017008034
357
SCREW BRACKET TO CROSS CONNECTION STRUT
357
SCREW , Replaced By: N304017008018
357
SCREW SUPPORT TO FENDER
357
SCREW , Replaced By: N304017008021
357
SCREW PIPE CLAMP
357
SCREW , Replaced By: N304017008016
357
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
359
WASHER , Replaced By: N009021008213
359
WASHER BRACKET TO LEFT SIDE MEMBER
359
WASHER , Replaced By: N000125010532
359
WASHER RADIATOR TO RUBBER MOUNTING
361
WASHER , Replaced By: N000125010532
361
WASHER RADIATOR TO RUBBER MOUNTING
361
WASHER , Replaced By: N000125008443
361
WASHER EXHAUST MUFFLER TO STRAP
361
WASHER EXHAUST MUFFLER TO STRAP
361
WASHER EXHAUST MUFFLER TO STRAP
362
NUT , Replaced By: N910113010000
362
NUT STRAP TO BRACKET
363
NUT , Replaced By: N910113010000
363
NUT STRAP TO BRACKET
363
NUT , Replaced By: N913004008001
363
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
363
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
363
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
365
SCREW , Replaced By: N304017008018
365
SCREW SUPPORT TO FENDER
365
SCREW SUPPORT TO FENDER
442
SCREW END PIECE TO EXHAUST PIPE M 10X25
442
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
442
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
442
SCREW END PIECE TO EXHAUST PIPE M 10X25
451
WASHER , Replaced By: N000125010532
451
WASHER RADIATOR TO RUBBER MOUNTING
451
WASHER RADIATOR TO RUBBER MOUNTING
451
WASHER COVERING TO BRACKET
458
NUT , Replaced By: N910113010000
458
NUT STRAP TO BRACKET
458
NUT STRAP TO BRACKET
461
BRACKET COVERING
461
BRACKET COVERING
461
BRACKET COVERING
461
BRACKET CROSS CONNECTION
466
BRACKET STRUT TO CROSS MEMBER
469
WASHER , Replaced By: N007349010007
469
WASHER STRUT TO CROSS MEMBER
470
WASHER , Replaced By: N009021010209
470
WASHER BRACKET TO COVERING
470
WASHER BRACKET TO COVERING
471
NUT , Replaced By: N910113010000
471
NUT STRAP TO BRACKET
471
NUT STRAP TO BRACKET
