Поз.
Артикул
Описание
145
VALVE (QUICK-RELEASE VALVE) WABCO
150
SCREW BRACKET TO CROSS CONNECTION STRUT
150
SCREW , Replaced By: N304017008034
155
WASHER , Replaced By: N000125008443
155
WASHER EXHAUST MUFFLER TO STRAP
160
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
160
NUT , Replaced By: N913004008001
165
BRACKET RELAY VALVE
170
SCREW , Replaced By: N304017010002
170
SCREW BRACKET TO SIDE MEMBER
175
NUT , Replaced By: N910113010000
175
NUT STRAP TO BRACKET
180
FITTING , Replaced By: A0029971372
180
FITTING SHUTTLE VALVE
185
T-FITTING LINE CONNECTION
190
NUT CHECK VALVE TO AIR RESERVOIR
195
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
195
THRUST RING CHECK VALVE TO AIR RESERVOIR
200
O-RING CHECK VALVE TO AIR RESERVOIR
205
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
210
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
215
SCREW. UNION SCREW LINE CONNECTION
220
FITTING SHUTTLE VALVE
220
FITTING FRONT AXLE II RELAY VALVE,CONNECTION: "24"
225
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
230
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "22"
230
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
230
SCREW PLUG , Replaced By: N000908022011
235
SEAL RING LOAD/NO-LOAD VALVE,CONNECTIONS: "20,21",5 727400
235
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
240
MUFFLER VALVE BLEEDING
240
MUFFLER VALVE BLEEDING
240
MUFFLER , Replaced By: A0004302470
245
SEALING CORD SUCTION LINE TO OIL PUMP
250
VALVE , Replaced By: A0044291544
250
VALVE. SHUTTLE VALVE (SHUTTLE VALVE) VOSS
335
VALVE (PARKING BRAKE VALVE) BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
335
VALVE PARKING BRAKE WITH TRAILER CONTROL "KNORR"
335
VALVE PARKING BRAKE WITH TRAILER CONTROL "BOSCH"
335
VALVE PARKING BRAKE WITH TRAILER CONTROL "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
335
VALVE (PARKING BRAKE VALVE) WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
340
HANDLETO 002 430 93 81
345
BUSHINGTO 002 430 93 81
345
BUSHING , Replaced By: A4421440050
345
BUSHING"WABCO"
350
PROTECTIVE CAPTO 002 430 93 81
355
LEVERTO 002 430 93 81
360
SPRING RETAINERTO 002 430 93 81
365
PINTO 002 430 90 81
365
PINTO 002 430 93 81
370
REPAIR KITBOSCH,TO 002 430 93 81
370
REPAIR KIT HAND BRAKE VALVE "WABCO"
375
BRAKE VALVE TRAILER CONTROL VALVE WABCO
380
REPAIR KITTO 001 431 37 05,4 375193
385
BRACKET TRAILER CONTROL VALVE
390
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
395
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
400
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
405
SCREW. UNION SCREW LINE CONNECTION
410
PIPE SOCKET 3/2-WAY VALVE,CONNECTION: "30"
415
FITTING BRAKE POWER REGULATOR W/RELAY VALVE, CONNECTION: "40"
420
LOCK RING LINE CONNECTION
420
SEAL RING , Replaced By: A0009940747
425
NUT COMBINATION CYLINDER,CONNECTION: "12"
430
LOCK LINE CONNECTION
430
LOCK , Replaced By: A0009945448
435
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
440
SCREW. UNION SCREW LINE CONNECTION
440
SCREW. UNION SCREW , Replaced By: A0009973734
445
SEAL RING
999
CROSS FITTING AIR DEHYDRATOR,CONNECTION: "21"
999
SEAL RINGWABCO
999
VALVE. REPAIR KIT SHUTTLE VALVE
999
VALVE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0034291444
999
VALVE (THROTTLE CHECK VALVE)
999
HEATERWABCO
999
HEATERBOSCH, Replaced By: A0005450333
999
HEATERKNORR
999
HEATER CARTRIDGEBOSCH
999
VALVE
999
MUFFLER TRAILER CONTROL VALVE
999
REPAIR KIT PRESSURE REGULATOR BOSCH,K 126821
999
REPAIR KIT PRESSURE REGULATOR KNORR,K 126821
999
REPAIR KITWABCO
999
AIR CLEANER COMPLETE TO BOSCH,KNORR
999
AIR CLEANER COMPLETE KNECHT:TO BOSCH,KNORR
