Поз.
Артикул
Описание
8
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR
8
LINE (HEATING PIPE) FROM ENGINE TO HEATING PIPE AT RADIATOR,K 068297
17
GASKET HEATING PIPE TO ENGINE
20
SCREW , Replaced By: N304017008021
20
SCREW PIPE CLAMP
23
BRACKET FEED LINE TO THERMOSTAT
26
CLAMP FEED LINE TO THERMOSTAT
29
SCREW COVER PLATE TO BRACKET
32
NUT , Replaced By: N913004006001
32
NUT PUMP TO BRACKET
35
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR,K 068297
35
HOSE FROM HEATING PIPE AT ENGINE TO HEATING PIPE AT RADIATOR
38
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
38
HOSE FROM HEATING PIPE AT RADIATOR TO CAB HEATING PIPE
41
CLAMP , Replaced By: N000000000667
41
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
44
LINE HEATING AND BREATHING
44
LINE HEATING LINES,K 003669
44
LINE HEATING AND BREATHING,5 708091K 096749
44
LINE HEATING AND BREATHING
44
LINE ,5 464667 - 5 528983, Replaced By: A6555001572, +001A6555013082
44
LINE HEATING AND BREATHING,K 096750
44
LINE FEED AND RETURN LINES TO HEATING
47
SCREW DE-AERATION LINE TO RADIATOR
