Поз.
Артикул
Описание
5
HOSE , ORDER BY THE METER, Replaced By: A0259978682
8
NUT. UNION NUT LINE CONNECTION
11
CUTTING RING. GLAND LINE CONNECTION
14
PIN BUSHING FOR LINE CONNECTION BEKA-MAX , TO 025 997 86 82
14
PIN BUSHING , Replaced By: A0005730753
23
LOOM TIE365 MM
26
PUMP
29
ELECTRIC MOTOR , Replaced By: A0005402488
32
SHAFT
35
CLAMPING PIN2X12 MM
38
PLUG NOT CONFORMING TO DANGEROUS GOODS TRAFFIC REGULATIONS (GGVS)
41
PUMP , Replaced By: A0005715401
44
PUMP , Replaced By: A0005719401
47
RESERVOIR , Replaced By: A0005700204
50
SEAL RING , Replaced By: A0005710780
53
VALVE , Replaced By: A0005711614
56
COVER GREASE FILLING
59
GASKET
62
COVER , Replaced By: A0005711703
65
RETAINING PLATE PUMP VOGEL,TO 000 571 54 01,70 01
69
71
SCREW , Replaced By: N910143008002
77
NUT HORN TO BRACKET M8
77
80
80
83
SCREW , WITH DIESEL ENGINE
86
WASHER COVERING TO CAB
89
NUT HEATING PIPE TO BRACKET
91
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
92
FITTING LINE CONNECTION VOGEL
95
SEAL CONE LINE CONNECTION VOGEL
98
PIN BUSHING , Replaced By: A0005730653
101
ELBOW , Replaced By: A0005733530
101
ELBOW LINE CONNECTIONS VOGEL, M 10X1
104
CONNECTOR TRAILER COUPLING,FRONT BEKA-MAX
104
CONNECTOR BEARING BRACKET,BRAKE SHAFT,AND BRAKE ANCHOR BEKA-MAX, M 8X1
104
CONNECTOR BEARING BRACKET,BRAKE SHAFT,AND BRAKE ANCHOR VOGEL, M 8X1
104
CONNECTOR TRAILER COUPLING,FRONTVOGEL
