Поз.
Артикул
Описание
8
P.T.O.
11
HOUSING. CASE P.T.O.
11
HOUSING. CASE , Replaced By: A0002647901
17
SPINDLE TWIN GEAR
26
GEAR (SPUR GEAR), FROM TRANSMISSION 004950 WITH ZF P.T.O.`S A 684 260 40 05, ZF-NO.: 0501 006 279
29
GEAR (SPUR GEAR), FROM TRANSMISSION 004950 WITH ZF P.T.O.`S A 684 260 40 05, ZF-NO.: 0501 006 279
32
LOCK SHIFTING SHAFT, FROM TRANSMISSION 004950 WITH ZF P.T.O.`S A 684 260 40 05, ZF-NO.: 0501 006 279
35
INNER RING TWIN GEAR
38
WASHER GEAR, AS REQUIRED 1.42 MM
38
WASHER GEAR, AS REQUIRED 1.68 MM
38
WASHER GEAR, AS REQUIRED 1.55 MM
41
SEAL RING , FROM TRANSMISSION 004950 WITH ZF P.T.O.`S A 684 260 40 05, ZF-NO.: 0501 006 279
44
SEAL RING , FROM TRANSMISSION 004950 WITH ZF P.T.O.`S A 684 260 40 05, ZF-NO.: 0501 006 279
47
WASHER SRREW PLUG
50
SCREW SRREW PLUG
56
SHAFT OUTPUT SHAFT
62
INNER RING OUTPUT SHAFT,REAR
65
GEAR P.T.O. CONTROL
68
LOCK GEAR
71
INNER RING OUTPUT SHAFT,FRONT
74
BEARING CAP OUTPUT SHAFT,FRONT
77
GASKET BEARING COVER, AS REQUIRED
80
SCREW COVER TO P.T.O. CASE
92
INTERMEDIATE FLANGE REAR P.T.O.
95
GASKET BEARING COVER, AS REQUIRED
95
GASKET INTERMEDIATE FLANGE AS REQUIRED 0.50 MM
101
SCREW INTERMEDIATE FLANGE TO P.T.O. CASE
107
SEAL RING OUTPUT SHAFT,REAR
110
COVER
113
GASKET SHIFT CASE TO P.T.O. HOUSING 0.50 MM
116
BRACKET
119
SCREW SHIFT CASE TO P.T.O. HOUSING
122
TYPE PLATE P.T.O. HOUSING
125
DOWEL PIN TYPE PLATE
128
PLATE P.T.O. TO TRANSMISSION
131
GASKET P.T.O., AS REQUIRED 0.50 MM
131
GASKET P.T.O., AS REQUIRED 0.25 MM
134
STUD P.T.O. TO TRANSMISSION
137
NUT
140
GASKET CASE,REAR
143
TRANSMISSION CASE COVER CASE,REAR
146
STUD BOLT , 637229
149
WASHER COVER TO P.T.O. CASE
152
NUT
