Mercedes A1249970145 - КОЛЬЦО УПЛОТНИТЕЛЬНОЕ

G 240-16 715.521 GETRIEBETEILE

25 CLUTCH - 150 OIL PUMP,OIL FILTER,OIL COOLER IL. 2

Поз.
Артикул
Описание
49
A9454300094
ACCUMULATOR
83
A9454300057
BRACKET PRESSURE ACCUMULATOR
86
A9454300157
BRACKET PRESSURE ACCUMULATOR
89
N910143008000
SCREW SPEED SENSOR TO REAR AXLE
92
N910143008002
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
107
A9454300881
VALVE , Replaced By: A9454301181
107
A9454301181
VALVE PRESSURE ACCUMULATOR
110
N000908012009
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
113
N007603012110
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
116
N000000006446
FITTING LINE CONNECTION
116
A0019972572
FITTING LINE CONNECTION, Replaced By: N000000006446
119
A0019970972
FITTING , NOT USED
125
A1249970145
SEAL RING SOLENOID VALVE TO ACCUMULATOR
131
N910143008017
SCREW 3/2-WAY VALVE TO BRACKET
155
A3899971572
FITTING OIL COOLER
158
A9429970471
FITTING CONNECTION OF OIL LINES
161
A9429970282
HOSE CONVERTER LOCK-UP COUPLING
