Поз.
Артикул
Описание
30
ROD , Replaced By: A6583001715
35
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
35
PULL ROD FROM CONTROL SHAFT BEARING TO INTERMEDIATE LEVER 400 MM, TO BE ADAPTED DURING ASSEMBLY
40
TURNBUCKLE TURNBUCKLE
45
NUT BALL PIVOT TO LEVER
50
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
55
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
60
BRACKET
60
BEARING SEPARATE-GAS CONTROL BEARING
60
BRACKET ,5 260272, Replaced By: A6193000036, +002A6153010088
60
BRACKET SEPARATE-GAS CONTROL BEARING
63
BRACKET SEPARATE-GAS CONTROL BEARING
65
LEVER (FOLLOWER LEVER)
65
LEVER (FOLLOWER LEVER)
65
LEVER (FOLLOWER LEVER)
67
LEVER (FOLLOWER LEVER)
68
LEVER (FOLLOWER LEVER)
70
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
75
COVERING
75
COVERING INTERMEDIATE BEARING
75
SLEEVE , 1 PIECE REQUIRED IN ADDITION TO BE ADAPTED DURING ASSEMBLY, Replaced By: A4073015088
75
COVERING , Replaced By: A6153010088
80
LOCK PLATE INTERMEDIATE BEARING
85
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
85
SCREW , Replaced By: N304017008016
88
SCREW EXHAUST MUFFLER TO STRAP
88
SCREW CLAMP TO BRACKET AND TO PIPE
90
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
90
NUT , Replaced By: N913004008001
92
POWER CYLINDER EXHAUST BRAKE
94
ROD EXHAUST BRAKE
96
BALL SOCKET PULL ROD TO LEVER
98
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
101
NUT BALL PIVOT TO LEVER
103
THREADED UNION , Replaced By: A6153000525, +001A6153030050, +001N000125006421, +001N000931006122, +001N000934006007
105
BALL PIVOT CONTROL LEVER TO INJECTION PUMP LEVER, Replaced By: N000000004467
105
SCREW CONTROL LEVER TO INJECTION PUMP LEVER
107
SCREW PUMP TO BRACKET
107
SCREW , Replaced By: N304017006016
109
HOLLOW SCREW HEATING CONNECTION
111
SEAL RING LINE CONNECTION
113
BEARING BRACKET REVERSING LEVER
113
BEARING BRACKET REVERSING LEVER
113
BEARING BRACKET REVERSING LEVER
115
LEVER REVERSING LEVER
117
SHAFT REVERSING LEVER
119
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
121
CLAMPING PIN CONTROL LEVER TO CONTROL SHAFT, TO BE ADAPTED DURING ASSEMBLY
121
CLAMPING SLEEVE , Replaced By: N308752004001
123
BRACKET CABLE
123
BRACKET CABLE
123
BRACKET CABLE
124
SHIM BRACKET AND RUBBER MOUNTING TO BEARING BRACKET
125
SCREW BRACKET TO SIDE MEMBER
125
SCREW , Replaced By: N304017010002
130
WASHER , Replaced By: N000125010532
130
WASHER RADIATOR TO RUBBER MOUNTING
135
NUT STRAP TO BRACKET
135
NUT , Replaced By: N910113010000
140
CYLINDER , Replaced By: A0004304926
140
CYLINDER , Replaced By: A0004303026
140
CYLINDER , Replaced By: A0004302726, +001A4039910222
140
CYLINDER INCREASE IN NUMBER OF REVOLUTIONS KNORR
140
CYLINDER
140
CYLINDER INTERMEDIATE SPEED STOP
152
REPAIR KIT
152
BUSHING , Replaced By: A0004340850
155
REPAIR KIT , Replaced By: A0024300060
155
REPAIR KIT SHIFTING CYLINDER TO KNORR, SZ 1130 I/74963,000 430 3026
160
NUT INTERMEDIATE SPEED STOP
165
BALL SOCKET ROD TO BALL PIVOT
170
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
175
SECURING CLIP. CIRCLIP
225
ELECTRIC CABLE FROM FUSE TO CHASSIS/CAB PLUG CONNECTION,4 784736
230
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
235
PIN BUSHING HOUSING UNIPOLAR
240
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
240
ELECTRIC CABLE , Replaced By: A3805402181
241
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
243
BOOT PRESSURE SWITCH SCREW-CONNECTION TO M 27X1
243
BOOT CABLE HARNESS EXTENSION
244
NUT PRESSURE SWITCH SCREW-CONNECTION M 24X1,5 129167
245
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 24X1,5 129167
246
PLUG SOCKET PRESSURE SWITCH SCREW-CONNECTION TO M 24X1
247
ROUND PIN BUSHING REAR "ENR" SOLENOID VALVE BRANCH-OFF 0.75-2.5MM2
250
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 24X1
250
PLUG SOCKET , Replaced By: A3805402181
257
ELECTRIC CABLE , Replaced By: A3805402281
257
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 27X1
264
PIN BUSHING HOUSING UNIPOLAR
271
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
278
PLUG FROM CHASSIS/CAB CONNECTION POINT TO TACHOGRAPH 2.5 MM2
285
BOOT CABLE HARNESS EXTENSION
292
NUT PRESSURE SWITCH SCREW-CONNECTION M 27X1
299
WASHER PRESSURE SWITCH SCREW-CONNECTION TO M 27X1,5 129167
306
PLUG SOCKET A B S SENSOR CABLE SCREW-CONNECTION
313
ROUND PIN BUSHING REAR "ENR" SOLENOID VALVE BRANCH-OFF 0.75-2.5MM2
321
PLUG SOCKET REPAIR VERSION, NOT FOR DANGER CATEGORY VEHICLES M 27X1
321
PLUG SOCKET , Replaced By: A3805402281
328
PIN BUSHING HOUSING UNIPOLAR
335
PIN BUSHING HOUSING UNIPOLAR
999
BALL PIVOT , Replaced By: A3129910120
999
SCREW PLUGROCKINGER,TYP 59 U150
999
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
999
NUT L.H. THREAD
999
SCREW DISTRIBUTOR TO CAB
999
SCREW REAR AXLE REGULATING SOLENOID VALVE M 8X95
999
WASHER
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
COTTER PIN CYLINDER TO BRACKET
999
ROD LOAD SENSOR CONTROL
999
LEVER (FOLLOWER LEVER)
999
SHAFT REVERSING LEVER
999
PIPE ELBOW (OIL FILLER PIPE)
999
PIPE ELBOW
999
BUSHING POWER CYLINDER TO CONTROL LEVER
999
LEVER REVERSING LEVER
999
LEVER POWER CYLINDER TO CONTROL LEVER
999
SHAFT REVERSING LEVER
999
BEARING BRACKET REVERSING LEVER
999
BUSHING"WABCO"
999
ELECTRIC CABLE FROM CAB PLUG CONNECTION TO SOLENOID VALVE,4 784736
999
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER, 415 5 014668 416 5 000515 417 4 972023
999
ROD FROM ACCELERATOR PEDAL TO INTERMEDIATE LEVER
999
BALL PIVOT LEVER
999
SEAL RINGWABCO
999
VALVE , Replaced By: A0049975736
999
GASKET KITKNORR
999
LOOM TIE LINE MOUNTING 280 MM
999
PISTON
999
SPRING
999
PROTECTIVE CAPWABCO
999
REPAIR KITTO 000 430 48 26,KNORR
