Поз.
Артикул
Описание
3
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
3
HOSE , Replaced By: A0009872827
8
FITTING , Replaced By: A0029906171
8
FITTING (PARTS KIT),LINE RUPTURE
13
UNION NUT LINE CONNECTION
13
UNION NUT LINE CONNECTION, Replaced By: N000000006239
18
GLAND , Replaced By: A0019901967
18
SEAL CONE LINE CONNECTION
23
BUSHING , Replaced By: N915062009000
23
SLEEVE LINE CONNECTION
28
HOLLOW SCREW RELAY VALVE,CONNECTION "2",LEFT
33
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
38
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
43
CONSOLE SPRING LOAD ACCUMULATOR BRAKE CYLINDER, 10/20 UP TO CHASSIS 4 405566,50/60 UP TO CHASSIS 4 398880
48
CONSOLE RIGHT BRAKE CYLINDER, 10/20 FROM CHASSIS 4 405567,50/60 FROM CHASSIS 4 398881
48
CONSOLE LEFT BRAKE CYLINDER, 10/20 FROM CHASSIS 4 405567,50/60 FROM CHASSIS 4 398881
53
CONSOLE SPRING LOAD ACCUMULATOR BRAKE CYLINDER
58
BRAKE CYLINDER SPRING LOAD ACCUMULATOR KNORR
58
BRAKE CYLINDER , Replaced By: A0004312414
58
BRAKE CYLINDER SPRING LOAD ACCUMULATOR BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
58
BRAKE CYLINDER SPRING LOAD ACCUMULATOR, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
62
CUPTO 000 431 24 14
62
CUPTO 000 431 50 14
62
PROTECTIVE CAPTO 000 431 24 14
62
CUPTO 001 431 65 14
62
CUPTO 000 431 76 14
62
CUP , Replaced By: A0015864342
62
CUPTO 000 431 24 14
67
SLIDETO 000 431 50 14,000 431 24 14
71
SEAL RINGTO 000 431 86 14
76
SEAL RINGTO 000 431 86 14
80
SEAL RINGTO 000 431 24 14
80
SEAL RINGTO 000 431 24 14
80
SEAL RINGTO 000 431 86 14
89
PISTONTO 000 431 86 14
93
STRAINERTO 000 431 86 14
99
FILTER BOTTOMTO 000 431 24 14
103
STUD
105
REPAIR KIT , Replaced By: A0034201724
105
REPAIR KITTO 001 431 65 14,000 431 24 14
109
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
114
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
118
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
118
FITTING ,4 667210
122
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
126
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
130
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
134
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
134
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
134
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
134
TEST CONNECTION
138
SCREW CONSOLE TO SIDE MEMBER
138
SCREW , Replaced By: N308676012026
138
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
142
LOCK WASHER FITTING TO BRACKET
146
NUT SUPPORT TO SIDE MEMBER
150
SCREW END PIECE TO EXHAUST PIPE M 10X25
154
NUT STRAP TO BRACKET
154
NUT , Replaced By: N910113010000
158
SCREW , Replaced By: N304017010002
158
SCREW BRACKET TO SIDE MEMBER
162
WASHER , Replaced By: A3859900540
162
WASHER BRACKET TO LEFT SIDE MEMBER
166
WASHER RADIATOR TO RUBBER MOUNTING
166
WASHER , Replaced By: N000125010532
170
NUT , Replaced By: N910113010000
170
NUT STRAP TO BRACKET
174
BRAKE INTERMEDIATE SHAFT SPRING LOAD ACCUMULATOR BRAKE CYLINDER
999
BRAKE CYLINDER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0014316514
999
PLUG
999
REPAIR KITTO 000 431 76 14
999
SEAL RING
999
BRACKET SPRING LOAD ACCUMULATOR
999
WASHER , Replaced By: A3859900540
