Поз.
Артикул
Описание
280
FRONT SPRING BRACKET FRONT AND REAR
280
FRONT SPRING BRACKET FRONT,4 348973
294
ANGLE RIGHT REINFORCEMENT
294
ANGLE LEFT REINFORCEMENT
343
SCREWM 14X15X31X48
343
FITTED SCREWM 10X11X25X38
343
SCREWM 14X15X29X46
343
SCREWM 12X13X12X29
343
SCREWM 16X16X22X40
343
SCREW , Replaced By: N308676012013
343
SCREW , Replaced By: A3959900501
343
SCREW , Replaced By: A0029908201
343
SCREW , Replaced By: A3229903101
343
SCREW , Replaced By: N308676016020
343
SCREW , Replaced By: N000961016118
343
FITTED SCREWM 18X19X57X85
343
SCREWM 10X11X26.5X46
343
SCREW CONSOLE TO FRAME
343
SCREWM 16X16X38X90
343
SCREWM 12X13X25X42
343
SCREWM 16X18X63X85
343
SCREWM 12X12X17X32
343
SCREW FRONT SPRING FRONT BRACKET TO SIDE MEMBER
343
SCREWM 14X14X24X42
343
SCREWM 14X15X17X34
343
FITTED SCREWM 10X11X14X28
343
SCREWM 16X17X22X42
343
SCREWM 14X15X21X38
343
SCREWM 16X16X32X50
343
SCREW PLATE TO SIDE MEMBER
343
SCREWM 12X12X10X25
343
SCREWM 14X14X18X34
343
SCREWM 16X18X18X40
343
SCREWM 16X18X38X60
343
SCREWM 14X14X18X32
343
SCREWM 12X13X13X30
343
SCREWM 12X13X15X32
343
SCREWM 12X13X18X35
343
SCREWM 14X14X22X40
343
SCREWM 12X13X58X80
343
SCREWM 16X18X26X48
343
FITTED SCREWM 10X11X24X40
343
SCREWM 12X12X15X30
343
SCREWM 12X13X21X38
343
SCREW MOUNTING USED FOR FRAME CONNECTION PARTS
343
SCREWM 12X12X11X26
343
SCREWM 12X12X13X28
343
SCREWM 14X15X15X32
343
SCREWM 14X15X18X35
343
SCREWM 12X13X23X40
343
SCREWM 16X16X30X48
343
SCREWM 14X15X19X36
343
SCREWM 12X13X35X52
343
SCREWM 14X15X35X52
343
SCREWM 12X14X13X35
343
FITTED SCREWM 18X19X33X55
343
SCREWM 14X14X32X50
343
SCREWM 16X16X20X45
343
FITTED SCREWM 18X19X25X45
343
FITTED SCREWM 18X19X38X60
343
SCREW , Replaced By: N000961018043
343
SCREW , Replaced By: A3169900014
343
SCREWM 16X16X20X38
343
SCREWM 14X14X27X45
343
SCREWM 14X15X27X44
343
SCREWM 12X13X63X85
343
HEXAGON HEAD BOLT , Replaced By: A0029902704
343
SCREWM 16X17X24X44
343
SCREW , Replaced By: A0009906314
343
SCREWM 18X18X23X45
350
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
350
NUT TORSION BAR TO BEARING BRACKET,5 904661
350
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
350
NUT STEERING SUPPORT TO FRAME
350
NUT CONSOLE TO SUPPORT
350
NUT , Replaced By: N910113012003
350
NUT , Replaced By: N910113014000
350
NUT , Replaced By: N910113016001
357
RIVET REINFORCEMENT TO SIDE MEMBER
357
RIVET10X24 MM, TO BE ADAPTED DURING ASSEMBLY
357
RIVET10X18 MM, TO BE ADAPTED DURING ASSEMBLY
357
RIVET12X28 MM, TO BE ADAPTED DURING ASSEMBLY
357
RIVET BRACKET TO FRAME
357
RIVET10X34 MM, TO BE ADAPTED DURING ASSEMBLY
357
RIVET12X26 MM, TO BE ADAPTED DURING ASSEMBLY
357
RIVET GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS 10X26 MM
357
RIVET REAR CROSS MEMBER 12X42 MM
357
RIVET14X55 MM, TO BE ADAPTED DURING ASSEMBLY
357
RIVET FRAME TRUSS TO SIDE MEMBER
427
ANGLE TRANSFER CASE WITH CROSS MEMBER TO FRAME
434
CROSS MEMBER TRANSFER CASE NO.3
441
SCREW BRACKET TO SIDE MEMBER
455
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
455
SCREW END PIECE TO EXHAUST PIPE M 10X25
455
SCREW BRACKET TO SIDE MEMBER M 14X1.5X35
455
SCREW , Replaced By: N308676012012
455
SCREW , Replaced By: N308676014020
462
WASHER , Replaced By: N000125010532
462
WASHER RADIATOR TO RUBBER MOUNTING
469
NUT STRAP TO BRACKET
469
NUT BRACKET TO SIDE MEMBER
469
NUT , Replaced By: N910113010000
469
NUT , Replaced By: N910113014001
469
NUT SUPPORT TO SIDE MEMBER
999
JOINT BEARING , Replaced By: A0009817231
999
JOINT BEARING , Replaced By: A0009817331
999
JOINT BEARING , Replaced By: A0009817231
999
LOCK , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6208910017
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
RUBBER BUFFER
999
RUBBER BUFFER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
PIN
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6205860031
999
SHIM CAB TO FRAME
999
BUSHING , NO LONGER AVAILABLE INDIVIDUALLY,BUT ONLY IN REPAIR KIT, Replaced By: A3875860531
999
DISC SPRING , Replaced By: A3275045082, +001A3878912010
