Поз.
Артикул
Описание
5
BRAKE VALVE SERVICE BRAKE KNORR
5
BRAKE VALVE SERVICE BRAKE WABCO
8
SPRINGTO 345 431 70 05
11
SPRINGTO 345 431 70 05
14
SPRINGTO 345 431 71 05
17
PISTONTO 345 431 71 05
17
PISTONTO 345 431 70 05
20
LOCKTO 345 431 70 05
23
LOCK RINGTO 345 431 71 05
23
LOCK RINGTO 345 431 71 05
26
LOCK RING
29
LOCK RING PLANETARY CARRIER
32
REPAIR KIT LARGE SCOPE TO 345 431 70 05
32
REPAIR KIT SMALL SCOPE TO 345 431 71 05
32
REPAIR KIT SMALL SCOPE TO 345 431 70 05
32
REPAIR KIT , Replaced By: A0014300460
35
GASKET BRAKE SHOE WITH LINING
38
SPRING WASHER BRAKE SHOE WITH LINING
41
NUT BATTERY CASE
47
SEAL RINGTO 006 997 00 72
50
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
53
SCREW PLUG
65
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
68
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
71
SWITCH EXHAUST BRAKE,K 251255
71
SWITCH TWO-CIRCUIT BRAKE VALVE
74
SEAL RINGTO 006 997 00 72
77
VALVE (QUICK BREATHER VALVE) VARGA
80
DIAPHRAGM ,058011
83
SEAL RING ,058011
86
REPAIR KITTO A 364 429 70 44
89
SCREW PLUG
92
SEAL RINGTO 006 997 00 72
95
ELBOW FITTING DIAPHRAGM CYLINDER,CONNECTION: "1,11"
95
ELBOW FITTING , Replaced By: A3849907071
98
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
101
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
101
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
101
THRUST RING LOCKING VALVE
104
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
107
BRACKET QUICK-RELEASE VALVE
110
SCREW BRACKET TO INTAKE MANIFOLD
113
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
116
VALVE (RELAY VALVE) KNORR
116
VALVE (RELAY VALVE),REAR AXLE
116
VALVE (RELAY VALVE) WABCO
119
REPAIR KITTO 003 429 30 44,KNORR
119
REPAIR KITWABCO
119
REPAIR KIT SMALL SCOPE TO 001 429 68 44
119
REPAIR KITKNORR
119
REPAIR KITTO 003 429 30 44
122
WASHER TRAILER PLUG SOCKET TO BRACKET
125
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
128
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
131
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
134
SEAL RINGTO 006 997 00 72
137
SEAL RING LINE CONNECTION
140
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
144
SEAL RINGTO 006 997 00 72
147
SCREW PLUG
150
SEAL RINGTO 006 997 00 72
153
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
156
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
156
THRUST RING LOCKING VALVE
156
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
159
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
162
FITTING LOCKING VALVE,CONNECTION: "2"
165
VALVE (TRAILER CONTROL VALVE) "KNORR"
165
VALVE TWO-WAY
171
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
174
SEAL RINGTO 006 997 00 72
177
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
180
SWITCH
180
SWITCH RELAY VALVE,CONNECTION "2",RIGHT
180
SWITCH SUPPLY PRESSURE,5 966147
183
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
186
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
186
THRUST RING LOCKING VALVE
186
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
189
NUT LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
192
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
195
SEAL RINGTO 006 997 00 72
999
VALVE BODYTO 002 429 95 44
