Поз.
Артикул
Описание
8
SEAL RING OUTSIDE BEARING BRACKET
8
SEAL RING OUTSIDE BEARING BRACKET
8
SEAL RING OUTSIDE BEARING BRACKET
8
SEAL RING , Replaced By: A0129973747
11
SNAP RING BEARING BRACKET TO AXLE
14
SEAL RING INSIDE BEARING BRACKET
14
SEAL RING , Replaced By: A0149972247
14
SEAL RING , Replaced By: A0129974147
14
SEAL RING INSIDE BEARING BRACKET
17
SEAL HOLDER , Replaced By: A9454230058
17
SEAL HOLDER BEARING BRACKET
26
REPAIR KIT BRAKE CAMSHAFT BEARING
110
BRAKE CAMSHAFT LEFT
110
BRAKE CAMSHAFT RIGHT, ONLY INSTALL PARTS HAVING THE SAME PART NUMBER
110
BRAKE CAMSHAFT , Replaced By: A6174210036
110
BRAKE CAMSHAFT , Replaced By: A6174210136
113
BRAKE ANCHOR LEFT BRAKE CAMSHAFT
113
BRAKE ANCHOR RIGHT BRAKE CAMSHAFT
116
SEAL RING INSIDE BEARING BRACKET
116
SEAL RING INSIDE BEARING BRACKET
116
SEAL RING , Replaced By: A0149972247
116
SEAL RING , Replaced By: A0129974147
116
SEAL RING INSIDE BEARING BRACKET
119
SEAL HOLDER BRAKE CAMSHAFT BEARING IN CASE
122
GREASE NIPPLE , Replaced By: N071412008102
122
GREASE NIPPLE
125
SCREW
125
SCREW , Replaced By: A9759900104
125
SCREW SUPPORT TO JOINT HOUSING M 14X35
128
SEAL RING SUPPORT TO JOINT HOUSING
131
ADJUSTER LEFT WABCO
131
ADJUSTER RIGHT
146
STOP WASHER ADJUSTER TO BEARING BRACKET
149
SPACER WASHER ADJUSTER,AS REQUIRED 0.50 MM
152
SPACER WASHER ADJUSTER,AS REQUIRED 1.50 MM
152
SPACER WASHER ADJUSTER,AS REQUIRED 2.50 MM
152
SPACER WASHER ADJUSTER,AS REQUIRED 2.00 MM
155
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
158
SPACER WASHER BEARING BRACKET TO AXLE
158
SPACER WASHER , Replaced By: A3464230752
161
LOCK RING CLUTCH LEVER TO PEDAL SHAFT
173
BRAKE ANCHOR RIGHT
173
BRAKE ANCHOR LEFT,DIAPHRAGM CYLINDER
173
BRAKE ANCHOR RIGHT,DIAPHRAGM CYLINDER
173
BRAKE ANCHOR LEFT
176
SCREW SUPPORT TO JOINT HOUSING M 14X40
179
SCREW CROSS MEMBER TO SIDE MEMBERS
179
SCREW CENTRAL BEARING CROSS MEMBER TO SIDE MEMBERS M 16X50
179
SCREW CENTRAL BEARING CROSS MEMBER TO SIDE MEMBERS M 16X50, SERRATED BOLT
182
SCREW STEERING ARM TO STEERING KNUCKLE M 16X70, SERRATED BOLT
182
SCREW , Replaced By: A0009907404
182
SCREW , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6529900504
183
BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE BOSCH,16"
183
BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE KNORR,16"
183
BRAKE CYLINDER (DIAPHRAGM CYLINDER),FRONT AXLE WABCO,16"
185
DIAPHRAGM , Replaced By: A0004315428
185
DIAPHRAGMWABCO
185
DIAPHRAGMTO 007 420 42 18,KNORR
188
CUPWABCO
188
CUPKNORR
194
PLUGTO 009 420 22 18,008 420 20 18
194
PLUGTO 694 420 71 18/72 18
197
REPAIR KITKNORR
200
NUT COMBINATION CYLINDER TO BEARING BRACKET
203
BRACKET LINE TO REAR AXLE, NOT USED
206
PIN WHEEL CYLINDER TO SLACK ADJUSTER
209
COTTER PINROCKINGER TYP 260 G140
