Поз.
Артикул
Описание
5
STEERING SUPPORT AT FRAME
8
BRACKET OIL LINES
11
SCREW VIBRATION ABSORBER TO FRAME M 12X1.5X55
11
SCREW STEERING BRACKET TO FRAME M 12X1.5X60
11
SCREW , Replaced By: N308676012018
14
WASHER SUPPORT TO FRAME,D 127794
17
NUT ALTERNATOR TO SUPPORT
26
SCREW BEARING BRACKET AND PLATE TO FRAME M 16X1.5X40
26
SCREW , Replaced By: N308676018001
27
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
27
FITTED SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
29
PITMAN ARM
32
DRAG LINK AT STEERING GEAR NAKATA
32
DRAG LINK AT STEERING GEAR TRW DO BRASIL
32
DRAG LINK AT STEERING GEAR
38
JOINT TO BE SCREWED INTO DRAG LINK TO 682 460 98 05
38
DRAG LINK END TO BE SCREWED INTO DRAG LINK TO 682 460 31 05
41
DUST CAP SCREWED PART OF JOINT TO 682 460 31 05,98 05,75 05,77 05
41
BOOT SCREWED PART OF JOINT TO 384 460 97 05,98 05,99 05
44
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
47
COTTER PINROCKINGER TYP 260 G140
50
BOOT
50
BOOTTO 384 460 92 05, NOT USED
50
BOOT FIXED PART OF JOINT TO 384 460 88 05
53
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
56
COTTER PINROCKINGER TYP 260 G140
59
CLAMP JOINT TO TIE ROD TO 693 460 70 05
59
CLAMP JOINT TO DRAG LINK TO 682 460 75 05
62
SCREW , Replaced By: N308676012018
65
NUT SUPPORT TO SIDE MEMBER
999
SPACER RING SCREWED PART OF JOINT TO 693 460 71 05
999
DRAG LINK END FIXED PART OF JOINT TO 384 460 98 05
999
PITMAN ARM , NOT USED
