Поз.
Артикул
Описание
5
BRAKE ANCHOR (BRAKE ANCHOR)
8
SCREW , Replaced By: A3469902604
11
SCREW BRAKE ANCHOR TO AXLE CASING
14
PROTECTIVE PLATE , Replaced By: A6954200044
17
PROTECTIVE PLATE , Replaced By: A6954200044
20
SCREW BRAKE SHOE TO BRAKE ANCHOR PLATE TO 302 420 11 16
23
SPACER WASHER ADJUSTER TO BRAKE CAMSHAFT
26
OIL BAFFLE (BRAKE ANCHOR)
29
PLUG PROTECTIVE PLATE
32
BRAKE CAMSHAFT WITH LUBRICATING BORE,LEFT
32
BRAKE CAMSHAFT WITH LUBRICATING BORE,RIGHT
32
BRAKE CAMSHAFT , Replaced By: A6234210236
32
BRAKE CAMSHAFT , Replaced By: A6234210136
35
BRAKE SHOE
35
BRAKE SHOE CAST VERSION
35
BRAKE SHOE , FIRST EXHAUST STOCK OF OLD PARTS UP TO REAR AXLE 742221, Replaced By: A3934202919
38
BUSHING ,669845
38
BUSHING ,669845
41
PIN , Replaced By: A6584210074
44
LOCK RING SHOCK ABSORBER TO BRACKET,1D 006005
47
ROLLER , Replaced By: A3014200039, +002A0039971548
50
BUSHING
50
BUSHING
53
PIN , Replaced By: A3074200339
56
FITTED WASHER BRAKE SHOE ROLLER
56
WASHER , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: N000988017100
59
LOCK RING ,825817, 301,303,304,305, 868276, 311,313,314825818, 301,303,304,305, 868277, 311,313,314 SEE SPARE PARTS LIST 740.3
62
SEAL RING BRAKE SHOE PIN TO BRAKE ANCHOR
65
SPACER WASHER BRAKE SHOE TO BRAKE ANCHOR
68
PIN BRAKE SHOE TO BRAKE ANCHOR PLATE,078418
71
LOCK BRAKE SHOE TO BRAKE ANCHOR
74
SCREW BRACKET TO STEERING
74
SCREW SELF-LOCKING M 10X20
77
SPRING , Replaced By: A6179931110
77
SPRING BRAKE SHOE IN WELDED VERSION
80
BRAKE LINING (BRAKE LINING SET),STANDARD 18.0 MM
80
BRAKE LINING (BRAKE LINING SET),REPAIR SIZE 0 16.70 MM X 160 MM
80
BRAKE LINING (BRAKE LINING SET),REPAIR SIZE II 19.50 MM X 160 MM
80
BRAKE LINING (BRAKE LINING SET),REPAIR SIZE I 18.8 MM
83
RIVET , Replaced By: A3079900197
83
RIVET BRAKE LINING 15 MM
83
PANHEAD RIVET BRAKE LINING TO BRAKE SHOE 15 MM
83
RIVET
85
BRAKE DRUM
999
PROTECTIVE PLATE PARTS KIT
999
SCREW , Replaced By: A3469900904
999
SCREW FRONT WHEEL BRAKE TO STEERING KNUCKLE
999
PIN , Replaced By: A3454217074
