Поз.
Артикул
Описание
6
HOSE FROM THERMOSTAT TO RADIATOR
16
HOSE FROM THERMOSTAT TO RADIATOR
17
HOSE HEAT EXCHANGER
20
CLAMP. LOOM TIE (DRY FILTER)
20
CLAMP CHARGE AIR INTERCOOLER
22
SEPARATOR
32
HOSE THERMOSTAT,HEATING CONNECTION 38 X 50 X 430
32
HOSE ,D 209702
32
HOSE LINE CONNECTION 38X50X100 MM
33
COOLING WATER PIPE RIGHT
34
CLAMP MAIN CABLE HARNESS TO FIRE WALL
36
SCREW , Replaced By: A4609900601
36
SCREW OVERLOAD PROTECTOR TO BRACKET
38
WASHER PLUG SOCKET TO BRACKET
41
NUT BRACKET TO FIRE WALL
44
HOSE THERMOSTAT,HEATING CONNECTION 38 X 50 X 430
47
CLAMP CHARGE AIR INTERCOOLER
47
CLAMP , USED WITH AIR BRAKE,FROM IDENT NO. A 059729 ALSO INSTALLED ON: A 059166,A 059217,A 059218,A 059268,A 059276,A 059356-A 059359,A 059411,A 059418,A 059419,A 059425,A 059426,A 059594,A 059613, A 059625,A 059626,A 059647,A 059648.
47
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
47
LOOM TIE. CLAMP HOSE TO HEATING PIPE
47
CLAMP HOSE TO FITTING AND TO OIL TANK
50
HOSE FROM RADIATOR TO EXPANSION TANK 12X21X1300
50
HOSE FROM EXPANSION TANK TO RADIATOR
53
LOOM TIE ELECTRIC CABLE MOUNTING
