Поз.
Артикул
Описание
96
BRACKET FUEL LINES TO TRANSMISSION
96
BRACKET COMPRESSED AIR LINES, Replaced By: A6205240340
98
SCREW BRACKET TO CROSS CONNECTION STRUT
98
SCREW , Replaced By: N304017008034
101
WASHER EXHAUST MUFFLER TO STRAP
101
WASHER , Replaced By: N000125008443
104
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
104
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
104
NUT , Replaced By: N913004008001
721
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
722
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
724
VALVE PRESSURE REGULATOR,4 478330
724
VALVE PRESSURE REGULATOR,4 478330
725
SCREW PLUG CONNECTION "1","2",4 478330
729
BRACKET (REGULATING VALVE),4 478330
730
SCREW REAR AXLE REGULATING SOLENOID VALVE
733
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
733
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
733
NUT , Replaced By: N913004008001
734
SCREW BRACKET TO CROSS CONNECTION STRUT
734
SCREW , Replaced By: N304017008034
738
LINE FROM BRAKE POWER REGULATOR TO REAR BRAKE HOSE 500 MM
739
LINE FROM CONNECTOR TO TEST CONNECTION 2800 MM,4 478330
741
GROMMET LINE MOUNTING 19/13 MM
743
BRACKET LEFT FRONT BRAKE HOSE TO FRONT AXLE
745
SCREW PIPE CLAMP
745
SCREW , Replaced By: N304017008021
747
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
747
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
747
NUT , Replaced By: N913004008001
758
BRAKE HOSE650 MM
758
BRAKE HOSE650 MM
758
BRAKE HOSE , Replaced By: A0004288935
761
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
761
BRACKET. LOCK , Replaced By: A6525040038
764
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
768
CONNECTOR OIL DELIVERY LINE
785
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
788
SCREW PLATE TO BRACKET
788
SCREW PLATE TO BRACKET, Replaced By: N000000001481
788
SCREW PLATE TO BRACKET, Replaced By: N007985006590
791
NUT PUMP TO BRACKET
791
NUT , Replaced By: N913004006001
793
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
802
LINE FROM TEST CONNECTION TO BRAKE POWER REGULATOR,CONNECTION "1",4 478495
804
BRACKET BRAKE POWER REGULATOR
806
SCREW FOR SPRING CLAMPS,5 193394
808
NUT SUPPORT TO SIDE MEMBER
810
BRAKE PRESSURE REGULATOR , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
812
SEAL RING VALVE TO VALVE,K 025179
813
SPRINGTO 000 431 46 12,001 431 12 12
814
VALVE PART
815
SPRING
816
SPRING
817
VALVE CLUTCH SLAVE CYLINDER
817
VALVE , Replaced By: A3075530107
817
VALVE , Replaced By: A0004310265
818
SEAL RING
819
GUIDE BUSHING
820
SPRINGTO 000 431 46 12,001 431 12 12
821
CUP
822
SNAP RINGTO 000 431 46 12,001 431 12 12
823
WOODRUFF KEY
824
SEAL RING
824
SEAL RING , Replaced By: A0129975448
825
NEEDLE BEARINGTO 000 431 46 12,001 431 12 12
826
LOCK RINGTO 000 431 46 12,001 431 12 12
827
AIR CLEANER
828
SPRING WASHER ALTERNATOR CONNECTION D+
829
SPRINGTO 000 431 46 12,001 431 12 12
830
PROTECTIVE CAP
831
PROTECTIVE CAP
833
HOLLOW SCREW HEATING CONNECTION
834
FITTING LINE CONNECTION
834
FITTING LINE CONNECTION, Replaced By: N000000006446
837
DISTRIBUTOR REAR AXLE,4 478330
837
VERTEILERSTUCK. DISTRIBUTOR REAR AXLE,4 478330
838
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
838
SCREW , Replaced By: N304017008028
839
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
839
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
839
NUT , Replaced By: N913004008001
840
SPACER TUBE FRONT AXLE REGULATING SOLENOID VALVE
846
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 1200 MM
849
BRACKET BRACKET TO RIGHT SIDE MEMBER
849
BRACKET , THE OLD PART MUST NO LONGER BE INSJTALLED, Replaced By: A3834280140
851
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
851
SCREW , Replaced By: N304017008027
853
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
853
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
853
NUT , Replaced By: N913004008001
855
BRAKE HOSE
855
BRAKE HOSE
855
BRAKE HOSE , Replaced By: A0024280535
856
MOUNTING PLATE FROM EXPANSION TANK TO RADIATOR
856
BRACKET. LOCK , Replaced By: A6525040038
858
TEST CONNECTION FRONT AXLE
863
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
863
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
863
NUT , Replaced By: N913004008001
870
LINE FROM DISTRIBUTOR TO BRAKE HOSE ON REAR AXLE 1100 MM
873
LINE FROM TEST CONNECTION TO RIGHT WHEEL CYLINDER 700 MM,4 644237
999
VALVE , Replaced By: A3075530107
999
VALVE GASKET KIT TO 003 429 16 44,BOSCH,UP TO 03.82
999
VALVEBOSCH
999
BLEEDER VALVE , Replaced By: A0004310265
999
BLEEDER VALVE , Replaced By: A0004310265
999
PROTECTIVE CAP , Replaced By: A0004217187
999
PROTECTIVE CAP , Replaced By: A0004210887
999
PROTECTIVE CAP ,5 962906
999
BUSHINGWABCO,5 433388
999
VALVE SEAT RINGWABCO,5 433388
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
DIAPHRAGM , Replaced By: A0004290745
999
DIAPHRAGM
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
ELBOW FITTING , Replaced By: A0004294638
999
DISTRIBUTOR ,4 342862
999
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
999
ADAPTER FITTING RESERVOIR TO SUPPORT
999
REPAIR KITTO 002 431 83 06, KNORR 90309
999
REPAIR KITTO 001 431 47 06,WABCO 2210, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KIT BLEEDER VALVE TO 001 431 67 05,BOSCH
999
REPAIR KITTO 001 431 06 06,BOSCH 0 481 039 101,5 148812
999
GASKET KIT FOUR-CIRCUIT PROTECTIVE VALVE BOSCH
999
REPAIR KITTO 001 431 84 06,KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITTO 000 430 56 81,WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE HAND BRAKE VALVE KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SPACER RING ,4 428462
999
GUIDE BUSHINGTO 000 439 95 14,4 847617
999
COVERTO 001 431 73 14,001 431 71 14
999
GASKET34X2X6 MM,GRAU
999
TEST CONNECTION
999
TEST CONNECTION CONNECTION: 4.2,4 719029
999
VALVE SEATGRAU
999
VALVE SEATTO 001 431 68 06,GRAU 37001, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
FILLER CAP
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
BRAKE PRESSURE REGULATOR
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
PROTECTIVE CAPTO 000 431 66 14
999
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
999
TEST CONNECTION FRONT AXLE
999
TEST CONNECTION REAR AXLE BRAKE CIRCUIT
999
PISTONTO 001 431 71 14,001 431 73 14
999
PISTONTO 000 431 95 14,4 847617
999
PISTONTO 000 439 95 14,4 847617
999
CUPBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
CUPTO 001 431 43 05,BOSCH-TEVES, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
RESERVOIR , Replaced By: A0004318702
999
SWITCH SUPPLY PRESSURE,5 966147
999
RING DRAIN VALVE TO 000 432 08 07, NOT USED
999
REPAIR KIT SLAVE CYLINDER TO 000 296 01 07
999
REPAIR KITWABCO
999
REPAIR KIT , Replaced By: A0004305860
999
SLEEVE , Replaced By: N915062006000
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
CAPTO 001 431 71 14
999
CROSS FITTING AIR RESERVOIRS I AND II,4 821954 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
BANJO UNION , Replaced By: N915052004006
999
T-FITTING , Replaced By: A0019901070
999
FITTING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "10"
999
HOLLOW SCREW , Replaced By: N915047012100
999
BANJO UNION , Replaced By: N915052006013
999
BUSHING , Replaced By: N915062004000
999
SPRING , Replaced By: A0009935205
999
SPRINGBOSCH,5 7999995 800000 - 5 8127305 900000 - 5 936365
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
FITTING , Replaced By: A0019972572
999
PLUG
999
BRAKE HOSE
999
VALVE , Replaced By: A0034291644
999
VALVE , Replaced By: A0044293144
999
VALVE (RELAY VALVE) GRAU
999
REPAIR KIT
999
REPAIR KIT PRESSURE REGULATOR WABCO
999
PROTECTIVE CAP
999
SEAL RINGTO 000 431 95 14,4 847617
999
CUPTO 002 431 04 06,BOSCH
999
SEAL RING28X2 MM,GRAU
999
SEAL RING86X2 MM,GRAU
999
SEAL RING 34X2,3 MM TO 001 431 68 06 34X2.3 MM,TO 001 431 68 06,GRAU
999
SEAL RING , Replaced By: A0009971548
999
GASKET , Replaced By: A0004311980
999
VALVE , Replaced By: A0014318406
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) WABCO, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0024312906
999
VALVE (FOUR-CIRCUIT PROTECTIVE VALVE) KNORR, 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
REPAIR KITTO 001 429 52 44
999
REPAIR KITBOSCH
999
REPAIR KITTO 001 429 20 44,BOSCH
999
REPAIR KIT TO 001 431 35 06 TO 001 431 35 06,KNORR
999
REPAIR KIT , Replaced By: A0004301407
999
T-FITTING INSIDE AND OUTSIDE AIR RESERVOIRS, FRONT CONNECTION
999
SEAL CONE
999
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
999
SEAL RINGTO 000 431 46 13,4 478330
999
SEAL RINGTO 000 431 46 13,4 478330
999
FITTING AIR RESERVOIR,CONNECTION: "13"
