Поз.
Артикул
Описание
65
DRIVE SHAFT FRONT AXLE, FROM TRANSFER CASE 005834
68
SHIFTING DOG LONGITUDINAL DIFFERENTIAL LOCK, FROM TRANSFER CASE 005834
71
GROOVED BALL BEARING DRIVE SHAFT,FRONT
74
SNAP RING
77
DRIVE GEAR SPEEDOMETER
80
FLANGE150 MM
86
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
89
THRUST WASHER FOLLOWER FLANGE TO PROPELLER SHAFT
92
PLANETARY CARRIER BOTTOM, FROM TRANSFER CASE 005834
95
GEAR FRONT PLANETARY CARRIER, FROM TRANSFER CASE 005834
98
LOCK RING FRONT PLANETARY CARRIER, FROM TRANSFER CASE 005834
101
TAPERED ROLLER BEARING PLANETARY CARRIER
101
TAPERED ROLLER BEARING ANNULUS, UP TO TRANSFER CASE 005833
101
TAPERED ROLLER BEARING ANNULUS,FRONT, UP TO TRANSFER CASE 005833
101
TAPERED ROLLER BEARING FRONT PLANETARY CARRIER
101
TAPERED ROLLER BEARING DRIVE SHAFT,FRONT
104
REPAIR KIT PLANET GEAR
107
NEEDLE PLANETARY CARRIER, FROM TRANSFER CASE 005834
107
NEEDLE PLANETARY CARRIER, FROM TRANSFER CASE 005834
110
WASHER PLANET GEAR
110
WASHER REAR PLANETARY CARRIER
113
SCREW PLANETARY CARRIER, FROM TRANSFER CASE 005834
140
SPACER WASHER AS REQUIRED 0.10 MM, FROM TRANSFER CASE 005834
140
SPACER WASHER AS REQUIRED 0.15 MM, FROM TRANSFER CASE 005834
143
ANNULUS REAR AXLE DRIVE, FROM TRANSFER CASE 005834
146
TAPERED ROLLER BEARING DRIVE SHAFT
146
TAPERED ROLLER BEARING DRIVE SHAFT
146
TAPERED ROLLER BEARING DRIVE SHAFT
149
SPACER WASHER AS REQUIRED 0.10 MM
149
SPACER WASHER AS REQUIRED 1.00 MM, FROM TRANSFER CASE 750.7012577 750.81 003240
149
SPACER WASHER DRIVE SHAFT,AS REQUIRED 0.15 MM
149
SPACER WASHER AS REQUIRED 1.70 MM, FROM TRANSFER CASE 750.7012577 750.81 003240
149
SPACER WASHER AS REQUIRED 2.40 MM, FROM TRANSFER CASE 750.7012577 750.81 003240
149
SPACER WASHER AS REQUIRED 1.35 MM, FROM TRANSFER CASE 750.7012577 750.81 003240
149
SPACER WASHER DRIVE SHAFT,AS REQUIRED 2.05 MM, FROM TRANSFER CASE 750.7012576 750.81 003239
152
TAPERED ROLLER BEARING ANNULUS,FRONT, FROM TRANSFER CASE 005834
152
TAPERED ROLLER BEARING ANNULUS, FROM TRANSFER CASE 005834
155
TAPERED ROLLER BEARING BOTTOM REAR COVER
155
TAPERED ROLLER BEARING ANNULUS,FRONT
155
TAPERED ROLLER BEARING ANNULUS,FRONT
155
TAPERED ROLLER BEARING FRONT
155
TAPERED ROLLER BEARING BOTTOM REAR COVER
158
COUPLING FLANGE FRONT TOP 180 MM
161
SCREWM 16X16X20X45
164
SCREW FOLLOWER FLANGE TO PROPELLER SHAFT
167
THRUST WASHER FOLLOWER FLANGE TO PROPELLER SHAFT
