Поз.
Артикул
Описание
2
SWITCH GEAR CLUSTER INDICATION
2
SWITCH , Replaced By: A0025458114
2
SWITCH , Replaced By: A0035451614
3
SEAL RING , Replaced By: N007603018100
3
SEAL RING SWITCH TO CASE COVER
4
PEDAL CLUTCH,4 244500
9
BRACKET AT CLUTCH PEDAL UNIT
14
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
19
SCREW COVER PLATE TO BRACKET
25
VALVE GEAR CLUSTER SHIFT
25
VALVE , Replaced By: A0004342201
26
CUP 3/2-WAY VALVE WABCO
27
HANDLETO 000 434 23 01
28
REPAIR KIT 3/2-WAY VALVE WABCO
29
SHIFT LEVER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6202680042, +001A6202680157
29
KNOB (SHIFT LEVER HANDLE), TO BE ADAPTED DURING ASSEMBLY
31
NUT SUCTION LINE TO OIL PUMP
36
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
36
PLASTIC PIPE RISING PIPE 4X6 MM
41
BANJO UNION , Replaced By: N915052004006
41
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
46
BANJO UNION HOSE WIDTH, / I.D., 4/10 MM
51
BUSHING , Replaced By: N915062004000
51
SLEEVE LEAK LINE
56
LOOM TIE LINE MOUNTING 280 MM
61
GROMMET FOR PASSAGE OF LINE
66
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
71
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
71
BANJO UNION , Replaced By: N915052006013
76
SLEEVE , Replaced By: N915062006000
76
SLEEVE LINE CONNECTION
81
SEAL RING PNEUMATIC VALVE
81
SEAL RING , Replaced By: N007603010110
88
HOLLOW SCREW LINE CONNECTION
94
LINE FROM CLUTCH TO TRANSMISSION
98
SEAL RING LINE CONNECTION
106
HOLLOW SCREW HEATING CONNECTION
111
SEAL RING , Replaced By: N007603010110
111
SEAL RING PNEUMATIC VALVE
117
FITTING 3/2-WAY VALVE,CONNECTION: "30"
121
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
121
FITTING , Replaced By: A0019909871
121
FITTING FROM PUMP TO CYLINDER
126
T-FITTING EXHAUST-BRAKE POWER CYLINDER
999
VALVE , Replaced By: A0002608157
999
CAP , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A6202680157
999
CLEANERTO 000 434 22 01
999
REPAIR KIT ADDITIONAL CLUSTER GEAR VALVE TO 000 434 06 01
999
BANJO UNION , Replaced By: N915052006003
999
BUSHING , Replaced By: A0007630043
999
FITTING , Replaced By: N915059004000
999
FITTING , Replaced By: N915059006000
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING , Replaced By: A0029905971
999
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
999
SEAL RINGTO 000 434 23 01
999
GROMMET
999
SPACER RING BRACKET TO REAR AXLE HOUSING,5 244591
999
HANDLE (GEARSHIFT LEVER KNOB)
999
HANDLE , Replaced By: A3432600040
999
GUMMED LABEL NINE-SPEED,ASHTRAY,5 032516
999
GUMMED LABEL NINE-SPEED,ASHTRAY,4 947402
999
BRACKET SOLENOID VALVE,4 411810
999
BRACKET SOLENOID VALVE,4 411810
999
LINE , Replaced By: A4064207226
999
BRACKET , Replaced By: A6454310740
999
COVER SHIFT LEVER KNOB LESS GEARSHIFT DIAGRAM
999
BRACKET FUEL LINE TO BELL HOUSING
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW CENTRAL LOCK TO CAB M 10X16
999
GLAND LINE CONNECTION
999
HEXAGON HEAD BOLT BRACKET TO TRANSMISSION
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
UNION NUT LINE CONNECTION
999
BANJO UNION HOSE WIDTH, / I.D., 6/10 MM
999
FITTING LINE CONNECTION TO FIRE WALL,5 726664
999
FITTING
