Поз.
Артикул
Описание
234
BRAKE COUPLING , Replaced By: A0004296830
234
BRAKE LINE COUPLING
236
BRAKE LINE COUPLING AT REAR CROSS MENBER
236
BRAKE LINE COUPLING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0004296730
236
BRAKE LINE COUPLING , Replaced By: A0004297530
236
BRAKE LINE COUPLING AT REAR CROSS MENBER
236
BRAKE LINE COUPLING AT REAR CROSS MENBER
240
SEAL RINGTO 000 429 75 30
242
VALVE DISCTO 000 429 48 30
245
SPRINGTO 000 429 16 30
248
GASKETTO 000 429 16 30
252
SNAP RINGTO 000 429 16 30
254
SEAL RINGTO 000 429 16 30
256
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
260
SEAL RINGTO 000 429 16 30
262
PIN
270
FITTING SHUTTLE VALVE,CONNECTION: "20"
270
FITTING , Replaced By: A0019972372
274
O-RING CHECK VALVE TO AIR RESERVOIR
276
THRUST RING CHECK VALVE TO AIR RESERVOIR
276
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
278
NUT CHECK VALVE TO AIR RESERVOIR
280
AIR CLEANER COMPRESSED AIR LINE
280
AIR CLEANER , Replaced By: A0004293895
281
FILTER ELEMENT
282
SEAL RING39.2X3.0 MM
282
SEAL RINGWABCO 000 0,36.2X3.0 MM
283
REPAIR KITWABCO 000 0
284
FITTING , Replaced By: A0029971172
284
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
284
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
286
RUBBER BUFFER , NOT USED
288
O-RING CHECK VALVE TO AIR RESERVOIR
290
THRUST RING CHECK VALVE TO AIR RESERVOIR
290
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
318
VALVE REAR AXLES I AND II BOSCH
318
VALVE FRONT AXLES I AND II "WABCO"
320
VALVE SEATWABCO
322
SEAL RING42.52X2.62 MM,WABCO
322
SEAL RING , Replaced By: A0179979048
324
SEAL RING82.22X2.62 MM,WABCO
326
SEAL RING74.20X5.70 MM,WABCO
327
REPAIR KIT RELAY VALVE WABCO
327
REPAIR KIT RELAY VALVE WABCO
328
MUFFLER TRAILER CONTROL VALVE
328
MUFFLER , Replaced By: A0004302370
328
MUFFLER BRAKE PRESSURE REGULATOR BREATHING,5 419692
330
O-RING CHECK VALVE TO AIR RESERVOIR
332
THRUST RING CHECK VALVE TO AIR RESERVOIR
332
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
334
BRACKET RELAY VALVE TO CROSS MEMBER
336
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
336
SCREW , Replaced By: N304017008016
338
NUT , Replaced By: N913004008001
338
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
340
FITTING ,4 667210
342
FITTING DELIVERY LINE TO PUMP
344
HOLLOW SCREW FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
344
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
346
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
348
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
350
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
352
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
SEAL RING LINE CONNECTION
999
PLUG TWO-CIRCUIT BRAKE VALVE,CONNECTIONS: "21,22", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
REPAIR KITWABCO
999
REPAIR KITTO A 000 429 11 31
999
FITTING AIR CLEANER
999
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
999
SPRINGTO 000 429 16 30
999
VALVE DISCTO 000 429 48 30
999
VALVE TAPPETTO 000 429 16 30
999
VALVE PARTTO 000 429 16 30
999
NUTTO 000 429 16 30
999
SPRING CAPSULETO 000 429 16 30
999
COVERTO 000 429 16 30,BOSCH
999
SPRING RETAINERVOSS
999
PISTONVOSS
999
SPACER RING ,4 428462
999
REPAIR KITKNORR
999
REPAIR KIT PRESSURE REGULATOR BOSCH,241
999
BRAKE LINE COUPLING , Replaced By: A0004297530
999
COVERWABCO
999
COVERTO 000 429 48 30
999
VALVE CONEBOSCH
999
VALVE CONE , Replaced By: A0004290391
999
REPAIR KIT BRAKE LINE COUPLING TO 000 429 68 30
