Поз.
Артикул
Описание
3
TANK , 993034
4
TANK , Replaced By: A0004664502
5
TANK OIL
6
FITTING , 993034
9
SEAL RINGTO 000 466 38 02
9
SEAL RING , Replaced By: A0059970848
12
CONNECTOR , 993034
15
CONNECTOR , 993034
16
CONNECTORTO 000 466 38 02
18
FILTER CARRIER , 993034
19
FILTER CARRIERTO 000 466 38 02
21
FILTER , 993034
22
FILTER
23
VALVE DISC , 993034
26
SPRING , 993034
27
BRACKET
29
GASKET , 993034
29
GASKET , Replaced By: A0004660580
30
SEAL RINGTO 000 466 38 02
31
SEAL RING
32
COVER , 993034
33
COVERTO 000 466 38 02
34
FILLER CAP
35
COVER , 993034
36
PIPETO 000 466 38 02
37
OIL DIPSTICK
37
OIL DIPSTICK , Replaced By: A0004660867
38
GASKET , 993034
41
WASHER , 993034
44
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
44
SCREW , Replaced By: N304017008016
45
NUT , 993035
46
SPACER TUBETO 000 466 38 02
47
BRACKET OIL TANK
47
BRACKET OIL TANK
50
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
50
SCREW , Replaced By: N304017010028
53
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
54
SCREW OIL TANK TO BRACKET
56
NUT OIL TANK TO BRACKET
56
NUT , Replaced By: N913002006009
56
NUT PUMP TO BRACKET
56
NUT , Replaced By: N913004006001
61
UNION NUT LINE CONNECTION, Replaced By: N000000006239
64
SEAL CONE LINE CONNECTION
64
GLAND , Replaced By: A0019901967
67
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
67
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
67
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
70
LINE , NOT USED
70
LINE FROM HIGH PRESSURE HOSE TO STEERING, 993034
70
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO FITTING
70
LINE FROM HIGH PRESSURE HOSE TO STEERING, 993034
71
UNION NUT LINE CONNECTION, Replaced By: N000000006239
72
SEAL CONE LINE CONNECTION
72
GLAND , Replaced By: A0019901967
74
SCREW-IN FITTING DELIVERY LINE TO PUMP
75
HOSE , NOT USED
75
HOSE , Replaced By: A3859971682
75
HOSE , Replaced By: A6999974082
75
HOSE , Replaced By: A3439970582
76
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
76
CLAMP HOSE TO FITTING AND TO OIL TANK
77
LINE FROM STEERING TO OIL TANK, 993034
78
LINE FROM STEERING TO OIL TANK
82
UNION NUT LINE CONNECTION
86
GLAND LINE CONNECTION
90
SCREW-IN FITTING RETURN, FROM STEERING TO OIL TANK
95
LINE , Replaced By: A0004291601
95
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
98
UNION NUT LINE CONNECTION, Replaced By: N000000006243
101
GLAND , Replaced By: A0019901267
101
SEAL CONE LINE CONNECTION
104
HOSE , Replaced By: A3859971582
104
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
105
CLAMP , Replaced By: N000000000667
105
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
107
LINE FROM LINE TO OIL TANK, 993034
107
LINE FROM OIL TANK TO HOSE, NOT USED
107
LINE FROM LINE TO OIL TANK, 993034
107
LINE FROM RETURN LINE TO OIL TANK, 620.415 UP TO IDENT NO. 5 014668 620.416 UP TO IDENT NO. 5 000515 620.417 UP TO IDENT NO. 4 972023
112
BRACKET , Replaced By: A3812950440
112
BRACKET , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 493018, Replaced By: A3812950440
112
BRACKET COMPRESSED AIR LINE TO FOUR-CIRCUIT PROTECTIVE VALVE,5 720506
115
BRACKET , Replaced By: A6564660040
115
BRACKET DELIVERY AND SUCTION LINES TO FRAME
116
BRACKET DELIVERY AND SUCTION LINES TO FRAME
117
SCREW , Replaced By: N308676012026
117
SCREW DELIVERY AND SUCTION LINES TO FRAME M 12X35
118
NUT SUPPORT TO SIDE MEMBER
119
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
119
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
123
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
124
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
125
NUT , Replaced By: N913004006001
125
NUT PUMP TO BRACKET
126
BRACKET , Replaced By: A6205244040
126
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
127
BRACKET , Replaced By: A3875015820
127
BRACKET , Replaced By: A3524290740
127
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT, TO BE ADAPTED DURING ASSEMBLY
128
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
129
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
130
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
131
NUT , Replaced By: N913004006001
131
NUT PUMP TO BRACKET
132
BRACKET , Replaced By: A3604293140
132
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
CLAMP DRAG LINK END TO DRAG LINK LEMFOERDER
999
CLAMP DRAG LINK END TO DRAG LINK EHRENREICH
999
BADGE STEERING WHEEL, NO.8316INO.7C52INO.7B90INO.9051I II I
999
FILTER , Replaced By: A0004660604
999
COVER PLATETO 000 466 38 02
999
WASHER , Replaced By: A9402680552
999
CENTERING RINGTO 000 466 38 02
999
RUBBER SLEEVETO 000 466 38 02
999
SEALING CORD , Replaced By: A0059970848
999
SCREW , Replaced By: N000000001149
999
HOSE , Replaced By: A0009978152
999
HOSE , Replaced By: A0009978152
999
PROTECTIVE CAP
999
STEERING SHAFT , USED WITH SHORT MERCEDES-BENZ CAB, Replaced By: A6504600209
999
STEERING SHAFT
999
RING STEERING SHAFT
999
WASHER , Replaced By: A3814620475
999
BOOT , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 456943, Replaced By: A3814621196
999
PLUG TOP,5 220080
999
LINE RETURN, FROM STEERING TO OIL TANK,5 593344
999
BRACKET ,971569, Replaced By: A3874660840, +001N913004008004
999
DRAG LINK , EXHAUST STOCK OF OLD PART NUMBERS FIRST FROM IDENT NO. 4 298137-4 621300, Replaced By: A3874601405
999
DRAG LINK , Replaced By: A3874603505
999
DRAG LINKLEMFOERDER,5 593344
999
PITMAN ARM , UP TO IDENT NO. 4 118554,ALSO INSTALLED ON 4 127151-4 129897
999
HOSE , Replaced By: A3609971182
999
HOSE , Replaced By: A3609970982
999
STEERING SHAFTLEMFOERDER, USED WITH SHORT MERCEDES-BENZ CAB
999
STEERING SHAFT , USED WITH SHORT MERCEDES-BENZ CAB
999
SPACER WASHERTO 000 466 38 02
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
COTTER PINROCKINGER,TYP 260 G150,260 G140
999
WIRE STEERING BOX ASSEMBLY TO STEERING SUPPORT 600 MM
999
SCREW ,5 903514, Replaced By: N000960012353
999
SCREW TORSION BAR TO SHACKLE,5 903514
999
SCREW STEERING SUPPORT TO FRAME M 14X55
999
SCREW STEERING SUPPORT TO FRAME M 14X50
999
SCREW , Replaced By: N308676016006
999
SCREW , Replaced By: A0029903712
999
NUT STEERING WHEEL TO STEERING COLUMN
999
SCREW STEERING BOX ASSEMBLY TO STEERING SUPPORT
999
NUT STEERING SUPPORT TO FRAME
999
NUT , Replaced By: N910113014000
