HD 6/3 D-10/7,35 - 745.503 - 35 REAR AXLE
Поз.
Артикул
Описание
5
WHEEL HUB
8
FOLLOWER
11
SCREW , Replaced By: N308676014008
11
SCREW MOUNTING TO CONSOLE M 14X35
14
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
17
TAPERED ROLLER BEARING INSIDE
20
SEAL RING
23
THRUST WASHER
26
OIL COLLECTOR
29
TAPERED ROLLER BEARING OUTSIDE
32
THRUST WASHER
35
GROOVED NUT
38
LOCK PLATE
41
WHEEL MOUNTING BOLT
44
NUT REAR SPRING TO REAR AXLE
44
NUT , Replaced By: N308674020000
