Поз.
Артикул
Описание
4
BEARING BRACKET CLUTCH, IN CASE OF PEDAL BEARING BRACKET WITH SHIMS,DELIVER ADDITIONALLY: 3X 000939 008136,1X 620 290 03 34 UP TO IDENT NO. 5 238024, SEE SERVICE INFORMATION 29/4
4
BEARING BRACKET ,4 247126 FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 4 655107, Replaced By: A3812901219
8
WASHER , Replaced By: N000125008443
12
STUD BOLT BRACKET TO TRANSMISSION
16
NUT , Replaced By: N913004008001
19
VALVE 3/2-WAY VALVE
22
NUT SUCTION LINE TO OIL PUMP
25
BRACKET 3/2-WAY VALVE, UP TO IDENT NO.5 238024,FROM IDENT NO. SEE GROUP 29
28
SCREW BRACKET TO BELL HOUSING M 6X18
31
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
34
WASHER LINE TO CROSS AND SIDE MEMBERS
37
STOP PEDAL ASSEMBLY
40
LOCK RING , Replaced By: A0079942041
43
PEDAL CLUTCH,5 238025
43
PEDAL CLUTCH PEDAL,4 915383
46
SCREW CLUTCH PEDAL
49
NUT , Replaced By: N304035008001
52
PIN CLUTCH PEDAL,5 238024
55
NUT , Replaced By: N913004008001
58
SPACER TUBE CLUTCH PEDAL
61
NEEDLE BEARING
61
NEEDLE BEARING , Replaced By: A0119813410
61
NEEDLE BEARING , Replaced By: A0119813410
64
PAD BRAKE
67
SPRING CLUTCH PEDAL RESET
70
PIVOT PIN PEDAL TO BEARING BRACKET
73
LOCK PEDAL TO BEARING BRACKET
76
SCREW COVER PLATE TO BRACKET
79
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
82
LOCK RING
85
SPRING RETAINER SPRING TO PUSH ROD
88
SPRING (DEAD CENTER SPRING) 35 MM
94
SPRING RETAINER SPRING TO PUSH ROD
97
ROD OVER-CENTER ACTING SPRING
97
ROD OVER-CENTER ACTING SPRING
100
NEEDLE BEARING JOINT TO PIN
100
NEEDLE BEARING JOINT TO PIN
100
NEEDLE BEARING JOINT TO PIN
100
NEEDLE BEARING JOINT TO PIN
103
NUT
106
PIN PUSH ROD TO PEDAL
109
WASHER BRACKET TO CROSS MEMBER
112
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
115
REPAIR KIT DEAD CENTER SPRING, DELIVER ADDITIONALLY:1X 381 993 06 01
118
MASTER CYLINDER CLUTCH,LESS DE-AERATION
118
MASTER CYLINDER , Replaced By: A0012952906
118
MASTER CYLINDER , Replaced By: A0012956006
120
VALVE , Replaced By: A3075530107
120
VALVE CLUTCH SLAVE CYLINDER
124
PROTECTIVE CAP , Replaced By: A0004217187
124
PROTECTIVE CAP ,5 962906
128
INTERMEDIATE PIECE CLUTCH MASTER CYLINDER
132
PLUG , Replaced By: A0009971186
132
PLUG
136
REPAIR KIT TO MASTER CYLINDER HAVING SYNTHETIC PISTON TO 001 295 60 06
136
REPAIR KIT , Replaced By: A0002903412
136
REPAIR KIT TO MASTER CYLINDER HAVING ALUMINUM PISTON TO 000 295 68 06,001 295 29 06
140
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
144
SCREW DELIVERY AND SUCTION HOSES TO COUPLING MOUTH CROSS MEMBER,5 598039
148
ROD MASTER CYLINDER
152
NUT , Replaced By: N304035008001
156
ARTICULATION PIECE CLUTCH MASTER CYLINDER
156
ARTICULATION PIECE CLUTCH MASTER CYLINDER
160
NEEDLE BEARING JOINT TO PIN
160
NEEDLE BEARING JOINT TO PIN
160
NEEDLE BEARING JOINT TO PIN
160
NEEDLE BEARING JOINT TO PIN
164
WASHER BRACKET TO CROSS MEMBER
168
LOCK PLATE PUSH ROD TO CLUTCH PEDAL
172
BEARING BRACKET BRAKE
176
WASHER , Replaced By: N000125008443
180
STUD BOLT BRACKET TO TRANSMISSION
184
NUT , Replaced By: N913004008001
188
EXPANSION PLUG STEERING COLUMN END 20 MM,4 4307305 062722
188
EXPANSION PLUG , Replaced By: A0009973220
188
PLUG , Replaced By: A0009972020
190
PLUG CAB FLOOR SEALING
196
SPACER TUBE , Replaced By: A3604270253
196
SPACER TUBE BEARING BRACKET TO WINDOW SILL GIRDER
196
SPACER TUBE BEARING BRACKET TO STEERING COLUMN BRACKET
200
WASHER , Replaced By: A4039900040
200
WASHER BEARING BRACKET TO STEERING COLUMN BRACKET
202
SPRING WASHER STEERING COLUMN BRACKET TO CAB
204
SCREW CLUTCH TO FLYWHEEL
208
PEDAL BRAKE
212
STOP
216
SPACER TUBE
220
NEEDLE BEARING
220
NEEDLE BEARING , Replaced By: A0119813410
220
NEEDLE BEARING , Replaced By: A0119813410
224
PAD BRAKE
228
PIN ROD TO BRAKE PEDAL
236
WASHER BRACKET TO CROSS MEMBER
238
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
240
PIVOT PIN PEDAL TO BEARING BRACKET
244
LOCK RING
248
SPRING BRAKE PEDAL RELEASE SPRING
252
LOCK , Replaced By: A6732920073
252
LOCK CLUTCH AND BRAKE PEDAL PINS TO BEARING BRACKETS
256
SCREW , Replaced By: N304017006018
260
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
264
YOKE OPERATING ROD,K 202311
268
ROD , Replaced By: A9702900039
268
ROD PISTON ROD AND PUSH ROD
272
NUT , Replaced By: N304035008001
999
BOOTTO 001 295 30 06
