Поз.
Артикул
Описание
11
AXLE HOUSING
11
AXLE HOUSING , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
47
HOUSING (PINION HOUSING)
53
COVER THROUGH DRIVE
53
COVER , Replaced By: A3553530408
59
CYLINDRICAL PIN FOR REPAIR PURPOSES ONLY, 101-103,110-116,119,121,122 UP TO IDENT NO. 4 477510 FROM IDENT NO. SEE MICROFICHE 750.5 130 UP TO IDENT NO. 4 758189 FROM IDENT NO. SEE MICROFICHE 750.2
65
SCREW RADIATOR PROTECTIVE GRILLE TO ANGLE
89
RING GEAR AND PINION RATIO: 29:25
89
RING GEAR AND PINION RATIO: 29:25
95
TAPERED ROLLER BEARING DRIVE SHAFT,REAR
95
TAPERED ROLLER BEARING DRIVE SHAFT,REAR
95
TAPERED ROLLER BEARING DRIVE SHAFT,REAR
95
TAPERED ROLLER BEARING DRIVE SHAFT,REAR
95
ROLLER BEARING DRIVE SHAFT,REAR
101
ROLLER BEARING DRIVE SHAFT,FRONT
101
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED
101
TAPERED ROLLER BEARING DRIVE SHAFT BEVEL GEAR/CROWN WHEEL, FRONT,AS REQUIRED
107
GEAR WHEEL HUB DRIVE
113
NUT PROPELLER SHAFT TO FOLLOWER FLANGE,5 091917
275
CYLINDER TRANSVERSE DIFFERENTIAL LOCK
281
GASKET SHIFTING CYLINDER TO INTERMEDIATE FLANGE
287
PISTON TRANSVERSE DIFFERENTIAL LOCK
293
SEAL RING SHIFTING CYLINDER
299
NUT
305
HEADLESS SETSCREW TRANSVERSE DIFFERENTIAL LOCK
311
SHAFT SHIFTING ROD,232175
317
SHIFTING FORK LONGITUDINAL DIFFERENTIAL LOCK, MAN AXLE
323
SPRING SHIFTING FORK
329
SCREW SHIFTING CYLINDER TO AXLE HOUSING M 8X70
335
SCREW PLUG
999
SEAL RING PINION HOUSING TO AXLE HOUSING
999
REPAIR KIT , Replaced By: A6583500323
999
WHEEL HUB DRIVE WHEEL HUB DRIVE
999
RING GEAR AND PINION , Replaced By: A9443501839
999
RING GEAR AND PINION RATIO: 27:18
999
DIFFERENTIAL GEAR LESS FLANGE, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
999
DIFFERENTIAL GEAR LESS FLANGE
999
REPAIR KIT THROUGH DRIVE
