Поз.
Артикул
Описание
5
STEERING BOX ASSEMBLYLS 8 BK
5
POWER STEERINGLS 8 BK, NOTE FOLLOWING WIS DOCUMENT WIS-NET#SI46.20-W-0001A#
8
VALVE PRESSURE LIMIT 130 BAR, M 18X1,5
8
VALVE PRESSURE LIMIT 130BAR, NOT CONTAINED IN PACK. CONTENTS OF: A6464602100
11
SEAL RING PRESSURE LIMIT
14
SEAL RING LINE CONNECTION
17
SCREW STEERING WORM SECTOR SHAFT ADJUSTMENT M10X53.5
17
SCREW STEERING WORM SECTOR SHAFT ADJUSTMENT M 6X39
17
SCREW STEERING WORM SECTOR SHAFT ADJUSTMENT M 10X39.5
17
SCREW STEERING WORM SECTOR SHAFT ADJUSTMENT M6X50.5
20
NUT STEERING WORM SECTOR SHAFT ADJUSTMENT
20
NUT ADJUSTING BOLT,PRESSURE REDUCTION VALVE M 6
23
SCREW FEED LINE AND RETURN LINE
26
WASHER BRACKET TO HEAT SHIELD
32
SCREW PLUG AIR DEHYDRATOR
35
SEAL RING PNEUMATIC VALVE
38
GASKET KIT STEERING WORM SECTOR SHAFT
41
DS BALL STEERING STEERING BOX
41
GASKET KIT STEERING BOX, Replaced By: A0004604000
44
GASKET KIT STEERING WORM IN CYLINDER COVER
45
HEXAGON HEAD BOLT STEERING WORM IN CYLINDER COVER M14X1,5 X30
999
SCRAPER HOUSING,FRONT
999
SEAL RING STEERING SHAFT BEARING IN COVER
