Поз.
Артикул
Описание
92
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
96
LINE FROM TEST CONNECTION TO RIGHT FRONT WHEEL 2200 MM,4 478329
96
LINE FROM MASTER CYLINDER TO FRONT AXLE TEST CONNECTION 2600 MM
96
LINE FROM DISTRIBUTOR TO VALVE 3200 MM
100
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
106
THRUST RING BUTT SCREW CONNECTION
108
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
108
SEAL RING , Replaced By: N007603012121
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT WABCO
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER FRONT AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER FRONT AXLE BRAKE CIRCUIT WABCO
726
BRAKE CYLINDER FRONT AXLE BRAKE CIRCUIT WABCO
726
BRAKE CYLINDER FRONT AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT WABCO
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT WABCO
726
BRAKE CYLINDER FRONT AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT WABCO
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER REAR AXLE BRAKE CIRCUIT KNORR
726
BRAKE CYLINDER FRONT AXLE BRAKE CIRCUIT WABCO
730
DIAPHRAGMTO 001 431 69 14,001 431 34 14
730
DIAPHRAGMTO 699 420 05 18
734
BUSHINGTO 0014316914,0014313414
738
LOCK RINGTO 0014316914,0014313414
750
REPAIR KIT BRAKE CYLINDER TO 001 431 83 14,001 431 84 14
750
REPAIR KIT BRAKE CYLINDER TO 001 431 79 14,001 431 80 14
750
REPAIR KIT BRAKE CYLINDER TO 0014311514,0014317014
750
REPAIR KIT BRAKE CYLINDER TO 001 431 81 14,001 431 82 14
753
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
756
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
759
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
759
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
759
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
759
TEST CONNECTION
762
PLUG
765
SCREW PLUGROCKINGER,TYP 59 U150
765
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
768
SEAL RING LINE CONNECTION
786
BRAKE MASTER CYLINDER (DIAPHRAGM CYLINDER)
786
BRAKE MASTER CYLINDER (DIAPHRAGM CYLINDER)
792
VALVE
794
STAY
797
CUP
798
CUP
800
VALVE CLUTCH SLAVE CYLINDER
800
BLEEDER VALVE , Replaced By: A0004310265
800
VALVE , Replaced By: A3075530107
803
PROTECTIVE CAP , Replaced By: A0004217187
803
PROTECTIVE CAP , Replaced By: A0004210887
803
PROTECTIVE CAP , Replaced By: A0004210887
803
PROTECTIVE CAP ,5 962906
815
REPAIR KIT BRAKE MASTER CYLINDER TO 003 430 86 01
818
CONNECTOR MASTER CYLINDER,CONNECTION "2.1",4 338292
821
HOHLSCHRAUBE FUR. HOLLOW SCREW MASTER CYLINDER,CONNECTION "2.1",4 338292
824
SEAL RING FUEL LINE TO FEED PUMP
825
FITTING TWO-WAY VALVE "12",4 4121264 691315
826
SEAL RING LINE CONNECTION
827
HOLLOW SCREW FUEL LINE TO FEED PUMP
827
HOLLOW SCREW , Replaced By: N915036010108
828
SEAL RINGTO 000 553 03 05,000 553 18 05,
828
SEAL RING FUEL LINE TO FEED PUMP
829
BRACKET BRAKE CYLINDER
830
BRACKET BRAKE CYLINDER
831
SCREW AT BRACKET
832
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
833
SCREW END PIECE TO EXHAUST PIPE M 10X25
834
NUT STRAP TO BRACKET
834
NUT , Replaced By: N910113010000
837
PLASTIC SECTION CABLE HARNESS TO ROOF RAIL
899
BRACKET CONSOLE TO SPRING LOAD ACCUMULATOR
900
SCREW PIPE CLAMP
900
SCREW , Replaced By: N304017008021
901
NUT , Replaced By: N913004008001
902
NUT , Replaced By: N913004008001
970
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
970
BRACKET RIGHT
970
SCREW , Replaced By: N304017008027
971
SCREW , Replaced By: N304017008039
971
NUT , Replaced By: N913004008001
971
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
976
LINE FROM DISTRIBUTOR TO BRAKE HOSE ON REAR AXLE 1100 MM
976
LINE FROM BRAKE POWER REGULATOR,CONNECTION "2",TO BRAKE HOSE 1150 MM
977
LINE FROM BRAKE POWER REGULATOR TO REAR AXLE BRAKE HOSE
977
LINE FROM BRAKE POWER REGULATOR TO BRAKE PRESSURE RELIEF 600 MM
981
CLAMP , Replaced By: N916016008200
981
CLAMP ,K 147121, Replaced By: N000000000319
981
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
982
SCREW CLAMP MOUNTING M 6X16
982
SCREW COVER PLATE TO BRACKET
982
SCREW , Replaced By: N000000001146
983
NUT , Replaced By: N913004006001
983
NUT PUMP TO BRACKET
999
CONNECTOR OIL DELIVERY LINE
999
HANDLETO 001 430 17 81,KNORR
999
REPAIR KITTO 001 430 18 81/78 81
999
FILTER BOTTOMTO 000 431 24 14
999
VALVE (CHECK VALVE)
999
FILLER CAP , Replaced By: A0004316533
999
FILLER CAP , Replaced By: A0004317633
999
CUP , Replaced By: A0015864342
999
RESERVOIR , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
PISTONVOSS
999
HOSE , Replaced By: A0004358382
999
OUTER RACETO 003 429 11 44,VOSS,707221
999
BANJO UNION , Replaced By: N915052006005
999
ELBOW FITTING , Replaced By: A0019904371
999
BUSHING , Replaced By: N915062004000
999
SPRING , Replaced By: A0009935205
999
HOSE FROM PARKING BRAKE VALVE TO ELBOW FITTING
999
VALVE PARKING BRAKE WITH EMERGENCY RELEASE DEVICE AND TRAILER CONTROL KNORR
999
VALVE PARKING BRAKE KNORR
999
BRAKE BOOSTER ASSEMBLY , FROM CHASSIS 018154 ALSO INSTALLED ON 017661,017829 EXCEPT FOR 018155,018156,018159,018308,018310,018315,018317,018318,018327,018350,018355. EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 533350, Replaced By: A0024305630, +001A1262920074, +001N912011008000
999
BRAKE BOOSTER ASSEMBLY , UP TO IDENT NO. 352290 EXCEPT FOR 350368,350793,350843,350954,351074,351169,351284,351434,351903,352001,352271,352272. ALSO INSTALLED ON 352332,352759,353163,353868,354161.
999
SEAL RING , Replaced By: A0009971548
999
HOSE
999
REPAIR KIT , Replaced By: A0034201724
999
THRUST RINGVOSS,707221
999
BRAKE MASTER CYLINDER , 10/50 FROM CHAS.145737-162733 ALSO INSTALLED ON 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660, 145697,145701 CONTINUED SEE FOOTNOTE 20
999
BRAKE MASTER CYLINDER
999
HOSE FROM RESERVOIR TO MASTER CYLINDER
999
SEAL RING , Replaced By: A0179979048
999
SEAL RING42.52X2.62 MM,WABCO
999
CLAMP , Replaced By: A0004760436
999
GASKET
999
PIN BRAKE PEDAL TO BRAKE BOOSTER
999
SPHERICAL PIECE , Replaced By: A3025860242
999
PROTECTIVE PLATE ,544549
999
PROTECTIVE PLATE
999
RATCHET ROD
999
BEARING BRACKET HAND BRAKE LEVER, UP TO CHASSIS 556499 EXCEPT FOR 553795,555902,556120
999
BRAKE LEVER
999
HANDLETO 341 420 00 88
999
BRACKET LEFT
999
BRACKET RIGHT
999
GROMMET , Replaced By: A0019877625
999
BRACKET BRAKE BOOSTER ASSEMBLY
999
BRACKET BRAKE BOOSTER BRACING
999
GASKET BRACKET TO FIRE WALL,707221
999
GASKET BRACKET TO FIRE WALL,707221
999
LINE WITH BEAD,10 MM
999
BUSHING , Replaced By: A0009973481
999
SUPPORT UPPER PART
999
SUPPORT ,556500 ALSO INSTALLED ON 553210,556146
999
LEVER INTERMEDIATE LEVER, FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
ROD ,556500 ALSO INSTALLED ON 553210,556146
999
NUT , FROM CHASSIS 556500 ALSO INSTALLED ON 553795,555902,556120
999
SPHERICAL PIECE ,556500 ALSO INSTALLED ON 553210,556146
999
BEARING BODY ,556500 ALSO INSTALLED ON 553210,556146
999
CONNECTOR HAND BRAKE LEVER,556500 ALSO INSTALLED ON 553210,556146
999
DAMPING RING
999
CLAMP BRAKE LINE MOUNTING
999
HOSE BRAKE LINE TO REAR AXLE,4 644238
999
SPRING ,556500 ALSO INSTALLED ON 553210,556146
999
HOSE BRAKE CABLE TO FORK 45 MM,556500 ALSO INSTALLED ON 553210,556146 ORDER BY THE METER
999
LINE FROM BRAKE MASTER CYLINDER TO LEFT FRONT WHEEL 1550 MM
999
REPAIR KIT , Replaced By: A3534200167
999
BASE STRAP
999
CLAMP , Replaced By: N916016008200
999
SCREW COVERING TO RAIL
