Поз.
Артикул
Описание
105
BRACKET SPARE WHEEL MOUNTING,869942
108
BRACKET SPARE WHEEL CARRIER,869829-869942
111
SCREW END PIECE TO EXHAUST PIPE M 10X25
114
NUT STRAP TO BRACKET
114
NUT , Replaced By: N910113010000
117
BEARING BRACKET ,869942
120
SCREW BRACKET TO SIDE MEMBER
120
SCREW , Replaced By: N304017010002
123
WASHER RADIATOR TO RUBBER MOUNTING
123
WASHER , Replaced By: N000125010532
126
NUT BRACKET TO SIDE MEMBER
129
PIN SPARE WHEEL TO BRACKET,869942
129
PIN SPARE WHEEL CARRIER TO SUBSTRUCTURE, 314.051-060 695199-711613 FOR USE WITH MERCEDES-BENZ PLATFORM 314.081-083 695199-711613
132
WASHER BRACKET TO FRAME
132
WASHER , Replaced By: N000125017016
135
COTTER PINROCKINGER TYP 260 G140
138
BRACKET SPARE WHEEL
141
BRACKET SPARE WHEEL,869942
144
SCREW END PIECE TO EXHAUST PIPE M 10X25
147
NUT STRAP TO BRACKET
147
NUT , Replaced By: N910113010000
150
NUT BRACKET TO CONSOLE, 314.051-060 695199-869828 FOR USE WITH MERCEDES-BENZ PLATFORM 314.081-083 695199-869828
153
LOCK SPARE WHEEL MOUNTING,007586-179227
156
RING
159
CHAIN BATTERY BASE FRAME TO BATTERY/APPARATUS SUPPORT
162
LOCK WASHER. SPRING LOCK WASHER DISC WHEELS TO FRONT AND REAR AXLES, Replaced By: N000000006796
165
SCREW BEARING BRACKET TO AXLE
168
BRACKET SPARE WHEEL MOUNTING,869942
171
PIN SPARE WHEEL TO BRACKET,869942
174
WASHER BRACKET TO FRAME
174
WASHER , Replaced By: N000125017016
177
COTTER PINROCKINGER TYP 260 G140
180
BRACKET SPARE WHEEL MOUNTING,869829-869942
183
NUT SPARE WHEEL CARRIER TO SIDE MEMBER
183
NUT , Replaced By: N308673016001
186
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
VALVE , Replaced By: A3104010113
999
SIDE RING , Replaced By: A0004015906
999
SIDE RING
999
BALANCING WEIGHT 50 DEGREES
999
BALANCING WEIGHT100GR.
999
BALANCING WEIGHT150 G.,4 187708
999
DISC WHEEL , Replaced By: A0024010401
999
HOOK BOLT , Replaced By: N000960012027
999
DISC WHEEL , Replaced By: A3184001402
999
CLAMPING PIECE , Replaced By: A3529900262
999
CLAMPING SCREW ,610285, Replaced By: A3529900262, +001A3524030529, +001N074361014351
999
DISC WHEEL , Replaced By: A0024010401, +001A6674010006
999
HUB CAP , PLASTIC VERSION, Replaced By: A3184000125
999
BRACKET ,695199-711613, Replaced By: A3184000939, +001A3184030103, +004N000125010513, +002N000933010047, +002N913002010000
999
CLAMPING SCREW , 006715
