Поз.
Артикул
Описание
6
CYLINDER METAL SPRING BELLOWS,REAR AXLE I
12
SEAL RING
12
SEAL RING , Replaced By: A0239975247
18
BOOT
24
PIN WIRE CABLE TO LEVER
30
WASHER EXHAUST MUFFLER TO STRAP
30
WASHER , Replaced By: N000125008443
36
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
42
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
42
SPRING WASHER , Replaced By: N000137008212
45
WASHER BRACKET TO FENDER BRACKET
48
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
54
CONSOLE METAL SPRING BELLOWS
57
BRACKET METAL SPRING BELLOWS
60
METAL SPRING BELLOWS ,4 9579425 498312
66
BRACKET METAL SPRING BELLOWS
69
BRACKET METAL SPRING BELLOWS TO REAR AXLE
72
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
72
SCREW , Replaced By: N308676012012
78
LOCK WASHER OIL PUMP TO TRANSMISSION CASE
84
COVERING INTERMEDIATE BEARING
84
COVERING , Replaced By: A6153010088
90
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
96
WASHER BEARING BRACKET TO BRACKET
102
COTTER PIN CYLINDER TO BRACKET
108
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
156
BRACKET TRAILING AXLE CONTROL
162
KNURLED HEAD SCREW PRESSURE SWITCH
168
NUT
168
NUT , Replaced By: N304032008006
174
STUD BOLT P.T.O. TO BELL HOUSING M 12X30
180
NUT END PIECE TO EXHAUST PIPE
186
BRAKE HOSE , Replaced By: A0004295135
186
BRAKE HOSE FROM FITTING TO REAR AXLE ONE-CIRCUIT PISTON CYLINDER 450 MM
189
CLAMP HOSE TO FITTING
192
LOOM TIE LINE MOUNTING 280 MM
198
T-FITTING FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24"
204
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
210
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
216
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
222
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
442
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
444
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
450
SEAL CONE
450
GLAND , Replaced By: A0019901667
456
SLEEVE LINE CONNECTION
462
UNION NUT
468
FITTING , Replaced By: A0009977172
468
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
474
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
480
SEAL RING LINE CONNECTION
486
SCREW PLUGROCKINGER TYP 59 G140,59 G150, Replaced By: N007604012105
486
SCREW PLUGROCKINGER,TYP 59 U150
492
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
498
FITTING DELIVERY LINE TO PUMP
999
PLUG
999
SLEEVE LINE CONNECTION
