Главная
›
Mercedes
›
VAN
›
SPRINTER 310 D,312 D
›
903.412
›
33 FRONT AXLE
›
080 FRONT AXLE DRIVE IL. 2
Mercedes N304017006016 - Винт M 6 X 16 8.8
SPRINTER 310 D,312 D 903.412
33 FRONT AXLE - 080 FRONT AXLE DRIVE IL. 2
Поз.
Артикул
Описание
5
A9014910830
PROTECTIVE PLATE FRONT RIGHT M 111 / OM 602
5
A9014912530
PROTECTIVE PLATE FRONT RIGHT
8
A9014910130
PROTECTIVE PLATE FRONT RIGHT
11
A9014900130
PROTECTIVE PLATE FRONT RIGHT M111 / OM 602
11
A9014911730
PROTECTIVE PLATE , Replaced By: A9014900130
14
N304017006016
SCREW PUMP TO BRACKET
17
N009021006208
WASHER COMPRESSED AIR LINE TO BRACKET
20
N910113006000
NUT HEATING PIPE TO BRACKET
23
N913023006001
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
23
N910112006001
NUT , Replaced By: N913023006001
24
N009021006208
WASHER COMPRESSED AIR LINE TO BRACKET
35
A9014912130
PROTECTIVE PLATE FRONT EXHAUST PIPE
38
A9014910817
ANGLE PROTECTIVE PLATE TO FRAME
41
N914128004303
SHEET METAL SCREW ALARM UNIT TO STRUT
44
A0009871145
LOCKING CAP
