Поз.
Артикул
Описание
1
BOX
1
BOX
2
SEAL RING LINE CONNECTION
3
SCREW PLUG , Replaced By: N000908012009
3
SCREW PLUG, FILLING. SCREW PLUG 3/2-WAY VALVE,CONNECTION: "10"
4
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
5
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
6
PLUG
7
SEALING CORD7.5X2 MM
8
SCREW
9
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
15
COVER WITH NEEDLE BEARING
16
NEEDLE BEARING38X48X20 MM
17
SEALING CORD *** 52X3 MM
18
SPACER WASHER2.5 MM
18
SPACER WASHER2,6 MM
18
SPACER WASHER2.7 MM
18
SPACER WASHER2.8 MM
18
SPACER WASHER2.9 MM
18
SPACER WASHER3.0 MM
18
SPACER WASHER3.1 MM
18
SPACER WASHER3,2 MM
18
SPACER WASHER3.3 MM
18
SPACER WASHER3,4 MM
19
SPRING WASHER , Replaced By: N000137008212
20
SCREW
21
SEALING CORD88X3 MM
22
BOX UPPER PART
22
BOX WITH BEARING BUSHING
23
BUSHING
24
SCREW
30
SEALING CORD , Replaced By: A0119973645
30
SEAL RING INTERMEDIATE SHAFT, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
31
SEALING CORD46X3 MM
32
SPACER TUBE
33
SEALING CORD30X3 MM
34
SPACER TUBE
35
LOCK
36
LOCK , Replaced By: A0009940640
36
SNAP RING
37
CONTACT SUPPORT
38
FLANGE
39
SPACER WASHER0.1 MM
39
SPACER WASHER0.12 MM
39
SPACER WASHER0.15 MM
39
SPACER WASHER0.2 MM
39
SPACER WASHER0.3 MM
39
SPACER WASHER0.4 MM
40
CONTACT PIECE , Replaced By: A0004640319
40
CONTACT PIECE
41
SCREW
42
SCREW
43
SPRING WASHER STEERING COLUMN BRACKET TO CAB
48
UNIVERSAL JOINT YOKE
49
CONNECTING ROD
50
PIN
51
LOCK RING
52
PISTON
52
PISTON
53
BEARING BODY
54
SCREW
55
SNAP RING
56
RING SCRAPER RING 74.4X80X2.8
57
RING SEAL RING 67X73X3
58
PISTON
58
PISTON OVERSIZE 0.1 MM, ONLY FOR EXPORT PURPOSE,AS PER SERVICE-INFORMATION 30/32 OF NOV.1965
59
PIN
60
LOCK RING
60
LOCK1.1 MM
60
LOCK1.2 MM
60
LOCK , Replaced By: A0039948941
60
LOCK1.3 MM
61
VALVE *** 11.33 MM, 335.002-004/013 UP TO CHASSIS 006235,335.103/104/113 UP TO CHASSIS 002744,336.UP TO CHASSIS 600307,339.UP TO CHASSIS 600070
62
BALL SHIFTING CYLINDER
63
WEB
65
WEB
66
SPRING
67
CYLINDRICAL PIN
68
SPACER TUBE
69
RING7.0 MM
70
SEALING CORD47X2.5 MM
71
SEALING CORD *** 40X2.5 MM
72
SPRING
73
RING
74
SEALING CORD38X2.5 MM
75
SNAP RING
76
RING
77
RING
86
SEAL RING30X40X7 MM
86
SEAL RING WITH DUST LIP 30X40X7 MM
87
INSULATING PART
88
WASHER
89
ROLLER
90
BALL RACE
91
BALL RACE
92
NEEDLE BEARING
93
SEAL RING , Replaced By: A0139974147
93
SEAL RING LESS DUST LIP 26X37X7 MM
94
LOCK RING
95
SEAL RING , Replaced By: A0059973747
95
SEAL RING , Replaced By: A0089979447
95
SEAL RING ON DRIVE END
96
BOOT ON DRIVE END
105
STEERG. WORM SECTOR SHAFT
105
STEERG. WORM SECTOR SHAFT
105
STEERG. WORM SECTOR SHAFT
106
SPACER WASHER *** 2.5 MM
106
SPACER WASHER2.6 MM
106
SPACER WASHER2.7 MM
106
SPACER WASHER2,8 MM
106
SPACER WASHER2.9 MM
106
SPACER WASHER3.0 MM
106
SPACER WASHER3,1 MM
106
SPACER WASHER3.2 MM
106
SPACER WASHER3.3 MM
106
SPACER WASHER3,4 MM
107
SEAL RING40X50X5 MM
108
SPACER RING
109
SEALING CORD *** 52X3 MM
110
SEALING CORD59X3 MM
111
FLANGE
111
FLANGE
112
NEEDLE BEARING40X50X20 MM
112
NEEDLE BEARING
113
SEAL RING
115
SPRING WASHER , Replaced By: N000137008212
116
SCREW
120
NUT
121
LINE
121
LINE , FROM STEERING 27219
122
SEALING CORD
123
HOLLOW SCREW
124
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
125
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
130
PITMAN ARM
130
PITMAN ARM
130
PITMAN ARM
130
PITMAN ARM
999
UNION NUT LINE CONNECTION, Replaced By: N000000006239
999
RIVETED NUT AT CROSS MEMBER, FROM CHASSIS 352291 EXCEPT FOR 352332,352759,353163,353868,354161 ALSO INSTALLED ON 350368,350793,350843,350954,351074,351169, 351284,351434,351903,352001,352271,352272
999
LOCK WASHERROCKINGER TYP 59 G140,59 G150
999
LOCK WASHER FITTING TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
SCREW STEERING BRACKET TO FRAME
999
SCREW STEERING TO STEERING BRACKET
999
SCREW CONSOLE TO CROSS MEMBER
999
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
999
NUT. HEXAGON NUT SHOCK ABSORBER MOUNTING
999
NUT
999
NUT IN CASE OF SUBSEQUENT INSTALLATION
999
NUT , Replaced By: N304032005005
999
SCREW PIPE CLAMP
999
CLAMP LINE MOUNTING
999
SCREW PLUG
999
SCREW PLUG FUEL TANK
999
SCREW PLUG , Replaced By: N007604014110
999
SEAL RING VALVE TO VALVE,K 025179
999
SEAL RING REAR AXLE REGULATING SOLENOID VALVE, CONNECTIONS: "1,2"
999
SEAL RING FUEL LINE TO FEED PUMP
999
GLAND , Replaced By: A0019901967
999
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
999
SCREW , Replaced By: N000961016065
999
SCREW CONSOLE TO SIDE MEMBER
999
SCREW , Replaced By: N308676012012
999
SCREW TOP BRACKET TO SHOCK ABSORBER M 16X120,TO 395 323 06 40,4 282786
999
SCREW RUBBER MOUNTING TO ENGINE SUPPORT M 16X1.5X60
999
SCREW STEERING BRACKET TO FRAME
999
SCREW PLATFORM MOUNTING
999
SCREW INTERMEDIATE LEVER TO FRAME M 12X1.5X40
999
SCREW CRANKSHAFT BEARING CAP TO CYLINDER CRANKCASE
999
SCREW SPARE WHEEL CARRIER TO SIDE MEMBER M 12X40
999
NUT
999
NUT , Replaced By: N308673012002
999
NUT BALL PIVOT TO LEVER
999
SCREW , Replaced By: N304017008021
999
LOCK RING , Replaced By: A0009949241
999
LOCK WASHER
999
WASHER GROUND STRAP TO ENGINE, UP TO CHASSIS 4 602752,EXCEPT FOR 551570-599999
999
COTTER PIN , UP TO IDENT NO.: 414221,FROM IDENT-NO.: 414222 SEE SPARE PARTS 766.1
999
SCREW SHIFT CASE TO SLOTTED GATE
999
SCREW
999
SCREWM 5X20
999
CLAMP AT ENGINE
999
SCREW ALTERNATOR TO ENGINE
999
CABLE HARNESS ELECTRIC
999
CABLE HARNESS ELECTRIC
999
CABLE HARNESS ELECTRIC
999
CABLE HARNESS ELECTRIC
999
CABLE HARNESS ELECTRIC
999
BRACKET ALTERNATOR TO ENGINE
999
STEERING SUPPORT
999
STEERING SUPPORT , Replaced By: A3384615840, +002N000960012171
999
STEERING BOX ASSEMBLY LESS PITMAN ARM
999
FRONT AXLE WITH BRAKES, FOR USE WITH SV 15750
999
FRONT AXLE TRILEX WHEEL 7.0-20
999
FRONT AXLE , ONLY FOR USE WITH SA 15752
999
FRONT AXLE WITH BRAKES, FOR USE WITH SV 15752
999
FRONT AXLE WITH BRAKES
999
FRONT AXLE
