Поз.
Артикул
Описание
5
SUPPORT ALTERNATOR
8
SUPPORT ,*0193151, Replaced By: A9061502770, +001A3441550072, +001A0069901701
8
SUPPORT ALTERNATOR
11
CLAMPING SLEEVE
14
SCREW. HEXAGON HEAD BOLT BRACKET TO TRANSMISSION CASE M12X1.75X55
17
HEXAGON HEAD BOLT ALTERNATOR TO SUPPORT M10X130
20
SCREW SUPPORT TO ALTERNATOR 156 MM,*0193152
20
SCREW SUPPORT TO ALTERNATOR 57 MM,*0193151
23
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
26
NUT ALTERNATOR TO SUPPORT,*0193152
29
SPACER RING BETWEEN ALTERNATOR AND SUPPORT, FRONT
32
SPACER RING BETWEEN INTAKE AIR HOUSING AND IGNITION COIL
38
BRACKET
41
BRACKET
44
HEXAGON HEAD BOLT CONSOLE TO REAR CROSS MEMBER AND TO FRAME SIDE MEMBERS M 10X40
47
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
50
SPACER RING
53
SPACER RING BETWEEN ALTERNATOR AND SUPPORT, REAR
56
HEXAGON HEAD BOLT. SCREW CLUTCH SLAVE CYLINDER TO BELL HOUSING
59
SCREW BRACKET TO TRANSMISSION, TO BE ADAPTED DURING ASSEMBLY
62
WASHER RADIATOR TO RUBBER MOUNTING
65
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
