Поз.
Артикул
Описание
120
LINE FROM TANK TO HOSE
132
HOSE
136
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
136
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
140
LINE FROM HOSE TO FEED PUMP
145
BANJO UNION FUEL LINE TO FUEL TANK
145
CONNECTOR FROM HOSE TO FEED PUMP, 344.058 UP TO SHASSIS 659793
150
HOLLOW SCREW
152
SEAL RING INJECTION PUMP
160
LINE FROM FUEL FILTER TO RUBBER HOSE,RETURN
170
NUT. UNION NUT RETURN
172
SEAL CONE , 344.058 UP TO SHASSIS 659793
172
BALL-TYPE NIPPLE. SEAL CONE , Replaced By: A3449907067
176
HOSE
177
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
177
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
180
LINE FROM HOSE TO TANK
190
HOSE , ORDER BY THE METER
190
HOSE , Replaced By: A3769978182
192
CLAMP LINE MOUNTING
194
LINE FROM CYLINDER HEAD TO HOSE
198
HOSE
200
LOOM TIE , Replaced By: A3509970290
200
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
200
CLAMP CONNECTION OF FUEL LINES ONE BELOW THE OTHER
202
LINE FROM HOSE TO TANK
204
NUT. UNION NUT RETURN
206
SEAL CONE , 344.058 UP TO SHASSIS 659793
206
BALL-TYPE NIPPLE. SEAL CONE , Replaced By: A3449907067
210
BRACKET FUEL LINE
211
BRACKET ,B 981730
211
BRACKET , Replaced By: A3444767036
213
SCREW , Replaced By: N304017010040
215
WASHER GROUND CABLE
216
LOCK WASHER , Replaced By: N912004010102
217
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
225
BRACKET FUEL LINES
230
CLAMP LINE MOUNTING
236
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
236
SCREW CAP TO BRACKET
239
LOCK WASHER EXTENSIBLE BRAKE VALVE TO CAB
242
NUT
248
SCREW , Replaced By: N304017010002
251
LOCK WASHER , Replaced By: N912004010102
254
NUT , 005,006,007,011,012,021,031,106,108,FROM CHASSIS A 012137,014,016,018 FROM CHASSIS A 007627
