Поз.
Артикул
Описание
5
HINGE SWIVELLING AREA, 180 DEGREES
5
HINGE SWIVELLING AREA, 270 DEGREES
5
HINGE , Replaced By: A9017400837
8
SCREW SPACER RING TO FLANGE
8
SCREW HINGE TO DOOR
11
SCREW ATTACHMENT GRAB HANDLE
11
SCREW HINGE ON CORNER PILLAR,CENTER
11
SCREW , Replaced By: A0009847429
11
SCREW FENDER TO BRACKET
14
BRACKET AT DOOR PILLAR
17
RIVET , Replaced By: A0039903897
17
RIVET LOWER PART RADIATOR
17
RIVET , Replaced By: A0029906297
17
RIVET RUNNING-ON WEDGE, BOTTOM
17
RIVET , Replaced By: N910003004135
17
RIVET , Replaced By: N910002004129
17
RIVET BINDING RAIL TO PLATFORM SIDE PANEL 4.8 X 9.5 MM
20
BRACKET SWIVELLING AREA, 180 DEGREES
20
BRACKET SWIVELLING AREA, 270 DEGREES
20
BRACKET , Replaced By: A9017600428
23
PLATE
29
SCREW MOUNTING PARTS
29
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
29
SCREW BRACKET MOUNTING
29
SCREW , Replaced By: N000000001149
29
SCREW , Replaced By: A0009844729
32
STOP , Replaced By: A9017400316
32
STOP SWIVELLING AREA, 180 DEGREES
32
DOOR CHECK SWIVELLING AREA, 270 DEGREES
35
DOOR CHECK SWIVELLING AREA, 270 DEGREES
38
PAD DOOR CHECK TO DOOR
44
SCREW DOOR CHECK TO DOOR M5X35
47
BRACKET RIGHT, TO BE ADAPTED DURING ASSEMBLY
47
BRACKET , Replaced By: A9017400714
47
BRACKET , Replaced By: A9017400714
50
SCREW TRAILER PLUG SOCKET TO BRACKET,K 061656 , N 824388
53
DOOR CHECK ON SIDE PANEL
54
SCREW DOOR CHECK TO DOOR
56
COTTER PIN BRACKET TO SIDE PANEL
59
NUT BRACKET TO SIDE PANEL
62
REINFORCEMENT TAILGATE LOCK
65
PLATE
68
PLATE
68
PLATE , Replaced By: A9017660819, +001A9017660076
