Поз.
Артикул
Описание
7
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
11
UNION NUT AIR COMPRESSOR LINE CONNECTION
11
UNION NUT BUTT SCREW CONNECTION
15
GLAND LINE CONNECTION
19
THRUST RING BUTT SCREW CONNECTION
23
SEAL RING , Replaced By: N007603012121
23
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
27
FITTING
31
BRAKE PRESSURE REGULATOR
31
BRAKE PRESSURE REGULATOR , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 412738, Replaced By: A0014311312
35
REPAIR KITTO 001 431 14 12
35
REPAIR KIT BRAKE POWER REGULATOR TO 000 431 37 12
39
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
39
SEAL RING LINE CONNECTION
39
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
43
FITTING RELAY VALVE,CONNECTION: "1,2"
43
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
43
FITTING RELAY VALVE,CONNECTION: "1,2"
47
BRACKET BRAKE POWER REGULATOR
51
SCREW , Replaced By: N304017010002
51
SCREW BRACKET TO SIDE MEMBER
55
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
59
NUT BRACKET TO SUPPORT AND TO END PIECE
63
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
67
NUT
71
LEVER , Replaced By: A6204310839
71
LEVER , Replaced By: A6744310039
71
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
71
LEVER , Replaced By: A3854310239
71
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
71
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
71
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
75
CONNECTOR PULL ROD TO LEVER
79
WASHER , Replaced By: N000125008443
79
WASHER EXHAUST MUFFLER TO STRAP
81
COTTER PINTO 345 460 94 05
83
CLAMP , Replaced By: A0059970190
83
HOSE CLAMP LINE MOUNTING
83
CLAMP , Replaced By: N000000000665
83
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
87
PULL ROD , Replaced By: N900331008420
87
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
91
NUT
95
METAL SPRING BELLOWS ,4 957941, Replaced By: A0004311718, +001N000961012047
95
METAL SPRING BELLOWS ,4 9579425 498312
99
YOKE BOTTOM
99
YOKE , Replaced By: A0004310667
103
BRACKET METAL SPRING BELLOWS
103
BRACKET METAL SPRING BELLOWS
103
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3464316740
107
BRACKET METAL SPRING BELLOWS,4 428485
107
BRACKET METAL SPRING BELLOWS,4 428485
111
SCREW , Replaced By: N308676016005
111
SCREW SUPPORT TO TRANSMISSION M 16X1.5X60
115
WASHER , Replaced By: N000125017016
115
WASHER BRACKET TO FRAME
119
SCREW METAL SPRING BELLOWS TO BRACKET,4 957941
123
LOCK WASHER FITTING TO BRACKET
127
BRACKET , Replaced By: A3464296040
127
BRACKET OIL LINE MOUNTING
131
SCREW , Replaced By: N304017008021
131
SCREW PIPE CLAMP
135
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
139
NUT
143
CLAMP , Replaced By: A6739950001
143
CLAMP DELIVERY AND SUCTION LINES TO STEERING
143
CLAMP LINE MOUNTING
147
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
151
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
155
NUT BALL PIVOT TO LEVER
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
159
GUIDE SIGN
163
ADHESIVE FOIL GUIDE SIGN
999
LINE , Replaced By: A0005516256
