Поз.
Артикул
Описание
4
ALTERNATOR , Replaced By: A0061545002
8
SEAL RING , NOT USED
11
SPACER RINGTO 004 154 79 02,004 154 82 02
15
BEARING BODYTO 004 154 79 02
15
BEARING BODY , Replaced By: A0001550101
18
SPRING WASHER SHIFTING YOKE BEARING
21
NUT SPRING SHACKLE TO SPRING REAR BRACKET
25
SPACER RINGTO 002 154 81 02
29
SPACER RINGTO 002 154 81 02
33
SEAL RINGTO 002 154 85 02
37
GROOVED BALL BEARING DRIVE END BEARING TO 002 154 85 02
41
CARBON BRUSH SET ,600808
45
DIODETO 005 154 01 02
48
DIODETO 005 154 01 02
51
DIODE EXCITER TO 004 154 79 02
60
ELECTRIC CABLETO 004 154 79 02,004 154 82 02
68
WOODRUFF KEY FLANGE TO SHIFTING TUBE
83
WASHER
89
BUSHINGTO 004 154 79 02,004 154 82 02
93
CONNECTORTO 004 154 79 02,004 154 82 02
97
GROOVED BALL BEARINGTO 002 154 81 02
102
GASKETTO 004 154 79 02
106
CONDENSER ,054430
110
BOOT HEATER PLUGS
110
BOOT , Replaced By: A0005463335
114
BOOT POS. CABLE
118
FAN ,600808
122
PULLEY ALTERNATOR
126
CLAMP
129
SCREW GUSSET PLATE TO SIDE MEMBER M 12X35
135
FITTED WASHER BELT TIGHTENER PULLEY
999
BUSHINGTO 006 154 50 02
999
RECTIFIER , Replaced By: A0001549716
999
RECTIFIER , Replaced By: A0001549716
999
COVERTO 002 154 85 02
999
BOOT , Replaced By: A0005460235
999
RECTIFIER
999
RECTIFIERTO 006 154 50 02
999
CARBON BRUSH SET , Replaced By: A0001547214
999
CARBON BRUSH SETTO 006 154 50 02
999
RECTIFIERTO 004 154 79 02
999
PULLEY ALTERNATOR
999
COUPLING HALF ,600808
999
FAN
999
PIN BUSHING WITH DETENT AND WITH CATCH FOR HOUSING 2,5 MM2
999
DIODETO 006 154 50 02
999
DIODETO 003 154 33 02
999
STUDTO 004 154 79 02,004 154 82 02
999
CONDENSER , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0001568301
999
CONDENSERTO 006 154 50 02
999
PLUG SOCKET , Replaced By: A0005453726
999
ALTERNATOR300 W / 12 V, FROM ENGINE 024721 ALSO INSTALLED ON 024514,024515059588
999
ALTERNATOR ,059589
999
ALTERNATOR
999
ALTERNATOR
999
PLUG , Replaced By: A0015457726
999
PLUG 4-POLE,5 064562
999
SEAL RING ,061991
999
ALTERNATOR1500 W,600808
999
BUSHING
999
SPRING
999
COUPLING HALF
999
BEARING BODY ALTERNATOR
999
WASHER
999
LINE
999
INTERMEDIATE SHAFT
999
GROOVED BALL BEARING DRIVE END BEARING 005 154 45 02/84 02
999
GROOVED BALL BEARING LEFT ALTERNATOR MOUNTING,061991
999
SCREW BEARING TUBE TO CLUTCH HOUSING, UP TO CHASSIS 679695
999
FITTED WASHER MANUAL CONTROL
999
CYLINDR. ROLLER BEARING ,061991
999
SNAP RINGTO 006 154 50 02
999
SNAP RING
