Поз.
Артикул
Описание
5
FUEL TANK TO BE MOUNTED ON THE RIGHT 400 L
5
FUEL TANK ALUMINUM 400 L
10
SCREW PLUG FUEL TANK
15
SEALING RING. SEAL RING FUEL TANK
20
SEAL RING FUEL GAUGE SENDER UNIT TO FUEL TANK
25
FUEL STRAINER FUEL TANK,K 169123
30
LOCK FUEL GAUGE SENDER UNIT CONNECTION
35
SUPPORT FUEL TANK TO FRAME
40
SUPPORT FUEL TANK TO FRAME
40
SUPPORT FUEL TANK TO FRAME
45
SUPPORT FUEL TANK TO FRAME
50
SHIM SUPPORT TO FRAME 6MM
50
SHIM MOUNTING PARTS 10 MM
55
HEXAGON HEAD BOLT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER M14X1.5X40
55
HEXAGON HEAD BOLT. SCREW MOUNTING PARTS M 14X1.5X35
55
HEXAGON HEAD BOLT. SCREW SUPPORT TO FRAME M14 X 1.5 X 55
60
NUT BATTERY/APPARATUS SUPPORT TO FRAME SIDE MEMBER
70
STRAP FUEL TANK TO CONSOLE
70
STRAP FUEL TANK TO CONSOLE
75
PIN STRAP TO SUPPORT
75
PIN , Replaced By: A9414750074, +002N912007016001
75
PIN , Replaced By: A9444750074
80
COTTER PIN STRAP TO SUPPORT
85
NUT STRAP TO SUPPORT M12X1.5
85
NUT BRACKET TO SIDE MEMBER M12X1.5
90
PAD BRAKE ANCHOR 111 MM
90
PAD BRAKE ANCHOR 53 MM
90
PAD STRAP 61 MM
999
CLIP RESERVOIR TO CAB FRONT PANEL
999
SHIM MOUNTING PARTS 7MM
999
SPACER TUBE MOUNTING PARTS, Replaced By: A0039921301
999
BUSHING MOUNTING PARTS 36X20.5X40MM, TO BE ADAPTED DURING ASSEMBLY
