Поз.
Артикул
Описание
10
BATTERY SUPPORT
20
BRACKET BRACKET TO BATTERY/APPARATUS SUPPORT
30
ADAPTER FITTING LINE CONNECTION TO ENGINE
40
PARKING PLUG SOCKET BLIND PLUG SOCKET,K 150752
50
SUPPORTING BODY TRAILER PLUG SOCKET,7-POLE
60
SUPPORTING BODY 15-POLE TRAILER PLUG SOCKET
90
CLAMP STEP
100
BRACKET BRACKET TO LEFT SIDE MEMBER
110
BRACKET SUPPORT TO SIDE MEMBER
120
WASHER BRACKET TO LEFT SIDE MEMBER
120
SPACER WASHER TORSION BAR TO BEARING BRACKET,5 904661
130
BRACKET STEP BEHIND CAB
140
SPACER RING BRACKET AND BEARING BRACKET TO FRAME
140
BUSHING , Replaced By: A4403220150
140
BUSHING MOUNTING PARTS, Replaced By: A3142420151
140
BUSHING TOOL BOX TO FRAME, TO BE ADAPTED DURING ASSEMBLY
150
STRUT BATTERY MOUNTING
155
BRACKET MOUNTING PARTS
160
BRACKET MOUNTING PARTS
163
BRACKET MOUNTING PARTS
170
BRACKET MOUNTING PARTS
180
CLAMP BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING,5 579088
180
CLAMP ELECTRIC CABLE MOUNTING
185
CLAMP BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
188
COVER BATTERY/APPARATUS SUPPORT
190
COVER BATTERY/APPARATUS SUPPORT
193
COVER BATTERY/APPARATUS SUPPORT
193
COVER BATTERY/APPARATUS SUPPORT
195
LOCKING HANDLE BATTERY/IMPLEMENT CARRIER,WITH LOCK
999
RAIL (INSTALLATION KIT)
