Поз.
Артикул
Описание
175
PUMP MODULE (UREA DELIVERY PUMP), FOR COMPONENT PARTS SEE SPARE PARTS LIST
175
PUMP MODULE , Replaced By: A0001402578
175
PUMP MODULE
178
FILTER ELEMENT WITH COVER
181
FITTING ADBLUE INPUT
184
SCREW-IN FITTING AT SCREEN M16X1,5
187
GROMMET SEAL
190
FITTING ADBLUE OUTPUT
193
FITTING ADBLUE RETURN LINE
196
FITTING COOLING WATER INLET/OUTLET M14X1.5 / 10MM, FROM 01.07.09
198
ACCUM. BAG
200
VALVE INSERT RESERVOIR BLADDER
202
DUST PROTECTION CAP RESERVOIR BLADDER 11X10.5 MM
208
HEXALOBULAR BOLT RESERVOIR BLADDER AT PUMP MODULE M5X16
211
UNION SCREW COMPRESSED-AIR-LINE PLUG-CONNECTION M 10, VOSS 232, Replaced By: A0009975034
214
STRAINER ON SUCTION SIDE
217
FILTER ADBLUE METERING DEVICE TO A000 140 05 78
220
GASKET HOUSING TO COVER
223
SCREW-IN FITTING HOUSING TO COVER TO A000 140 05 78
226
VALVE CRANKCASE BREATHER
229
VALVETO A000 140 05 78
232
REPAIR KIT O-RING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 10, SDF
